2.5.2 ENGINE INSTRUMENT MARKINGS
Powerplant instrument markings and their colour code significance are shown
below:
Instrument
Minimum
Range (Red)
Normal
Operating
Range (Green)
Caution Range
(Yellow)
Maximum
Range (Red)
RPM
None
1600-5500 RPM
5500-5800 RPM
5800-6400 RPM
Oil Temperature
0-50°C
50-110°C
110-130°C
130-150°C
Coolant
Temperature
None
0-120°C
None
120-150°C
Oil pressure
0-12 psi
29-73 psi
12-29 psi
73-102 psi
102-130 psi
Exhaust Gas
Temperature
None
700-900°C
900-950°C
950-1000 °C
Fuel pressure
0-2.18 psi
2.18-5.08 psi
None
5.08-5.8 psi
Manifold
Pressure
None
25-35.4 in.Hg
35.4-39.9 in.Hg
39.9-42 in.Hg
Fuel level
0-5 L
5-73 L
None
None
NOTE
Full power throttle setting is allowed for Max. 5 minutes and can lead to
engine RPM and MAP in yellow range.
