Section 4 – Installation and Deployment 32
Note
For Type 8221/8212 the “Function” differs on the wiring connection table shown for CPN 820-
6793 in
Appendix A.6. The wirng connection table shown in Table 4-3 replaces the wiring connection
table shown in
Appendix A.6 “ 8024-044/820-6793 Amphenol to AGP Cable Assembly” .
Table 4-3 Type 8221/8212 Wiring Connections
Amphenol Pin Number Cable Core Colour AGP Pin Number Function
F Screen and Drains 1 Screen
Earth Ring
J Red 2 Power +
K White 3 Ethernet Tx Data +
L Blue 4 Ethernet Tx Data -
G Green 5 Trigger
M Black 6 Ground and Power Return
A Orange 7 Ethernet Rx Data +
B Yellow 8 Ethernet Rx Data -
H Brown No Connection N/A
4.6.3 Type 8142/8182
The Type 8142/8182/Variant USBL transceiver interconnections are shown below.
