Sonoro ELITE - 2.3 Technical data

2.3 Technical data
Specification
Value
Dimensions
(W×D×H)
approx. 210 x 257 x 140 mm
Weight
approx. 3.7 kg
Operating temperature
0°C to +40°C
Display
2.8" TFT colour display
Frequency range, FM
87.50 MHz–108.00 MHz
DAB/DAB+
Band III, 174.928 MHz–239.200 MHz
Internet radio
More than 25,000 stations worldwide
Station presets 30 for each FM | DAB/DAB+ | Internet radio |
10 for Spotify
8 for each Deezer | Amazon Music|
CD support formats
CD-DA, CD-R*, CD-RW*
Audio CD, MPEG 1 Layer 3 (MP3), Windows Media Audio
(WMA, DRM not supported)
Sampling rate 16KHz~48KHz, bit rate max. 320kbps
(* Playback dependent on quality of recording and
medium)
USB charging
Output: DC 5V
2.1A
USB playback
Compatibility system: FAT 16, FAT 32 (not compatible
with NTFS or other systems)
AUX-IN
3.5mm jack Sensitivity: 300 mV
Streaming
Bluetooth | Spotify | Deezer | Amazon Music | DLNA | UPnP
My music support media
formats
AAC, AAC+, MP3, WAV, WMA, FLAC
Max. 16 bits, 2 channels, sample rate 48KHz
Network supported
IEEE 802.11 a/b/g/n, 2.4 & 5GHz bands, Ethernet
2.412GHz-2.472GHz / 5.18GHz – 5.24GHz / 5.26GHz-
5.32GHz / 5.50GHz-5.70GHz
Transmitted power
15dBm for 2.4GHz | 14dBm for 5GHz WiFi
Encrypted key
WEP, WPA, WPA2 (PSK), WPS
Multi-room function
Maximum of 5 speakers in a group (4 client and 1 server)
Bluetooth
Version 4.2, Profile : AVRCP v1.6
2.402GHz-2.480GHz
Transmitted power
9dBm
AC-Adapter, power
supply
Ten Pao Industrial Co., Ltd.
Model: S048CM1550290
Input: 100-240V ~ 50/60Hz 1,5A Max.
Output: 15.5V 2900mA
Battery
CR2032 (remote control)
Standby Power
< 1.0W
Network Standby
< 2.0W
64 © sonoro audio GmbH 2019
