Sony 5500 - Page 159

159
Menu List
Appendix
708 MASTER LEVEL
(HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Simultaneously adjusts the Y,
P
B
, and P
R
levels.
709 Y LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the Y level of the video
signal.
710 P
B
LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
B
level of the video
signal.
711 P
R
LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
R
level of the video
signal.
712 SETUP LEVEL (HD)
preset: 0
–10.0
[0.0]
10.0
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the setup level of the
video signal.
713 SYNC PHASE (HD)
preset: 0
–128
[0]
127
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
714 FINE (HD)
preset: 0
[0]
1024
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
720 HD OUT BLANK [through]
blank
Turns on and off vertical interval blanking processing of the
HD video signals output from the HD SDI OUTPUT
connectors and the FORMAT CONV. OUT (OPTION)
connectors.
through: Do not perform blanking processing.
blank: Perform blanking processing.
740 VIDEO GAIN (ALL)
(HD/UC/SD/DC)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the video gain of HD, UC, SD, and DC output. The
video level increases with larger setting values of this item.
741 CHROMA GAIN
(ALL)
(HD/UC/SD/DC)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the chroma gain of HD, UC, SD, and DC output.
The chroma level increases with larger setting values of this
item.
742 CHROMA PHASE
(ALL)
(HD/UC/SD/DC)
preset: 0
–127
[0]
127
Adjusts the chroma phase (HUE) of HD, UC, SD, and DC
output.
Item number Item Setting Function
[100 4000H ]
%
)
(
[100 4000H ]
%
)
(
[100 4000H ]
%
)
(
[100 4000H ]
%
)
(
[100 4000H ]
%
)
(
[100 4000H ]
%
)
(
