5-11
BKM-120D/127W/129X/142HD
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C303 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C304 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C305 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C306 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C307 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C321 1-163-143-00 CERAMIC CHIP 0.0012µF 5% 50V
C322 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C323 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C324 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C325 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C326 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C327 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C328 1-126-934-11 ELECT 200µF 20% 16V
C329 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C330 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C331 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C332 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C333 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C334 1-164-505-11 CERAMIC CHIP 2.2µF 16V
C335 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C336 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C337 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C338 1-126-934-11 ELECT 200µF 20% 16V
C339 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C340 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C341 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C342 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C343 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C344 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C345 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C361 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C362 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C363 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C401 1-126-933-11 ELECT 100µF 20% 16V
C402 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C403 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C404 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C405 1-163-241-11 CERAMIC CHIP 39PF 5% 50V
C406 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C407 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C408 1-107-715-11 ELECT 22µF 20% 50V
C409 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C410 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C421 1-126-933-11 ELECT 100µF 20% 16V
C422 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C423 1-126-933-11 ELECT 100µF 20% 16V
C424 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C451 1-126-933-11 ELECT 100µF 20% 16V
C452 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C453 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C454 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C455 1-163-241-11 CERAMIC CHIP 39PF 5% 50V
C456 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C457 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C458 1-107-715-11 ELECT 22µF 20% 50V
C459 1-163-107-11 CERAMIC CHIP 0.001µF 5% 50V
C471 1-126-933-11 ELECT 100µF 20% 16V
C472 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C473 1-126-933-11 ELECT 100µF 20% 16V
C474 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C551 1-126-933-11 ELECT 100µF 20% 16V
C554 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C555 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C556 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C557 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C558 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C601 1-126-933-11 ELECT 100µF 20% 16V
C602 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C603 1-126-933-11 ELECT 100µF 20% 16V
C604 1-126-933-11 ELECT 100µF 20% 16V
C605 1-126-933-11 ELECT 100µF 20% 16V
C606 1-126-933-11 ELECT 100µF 20% 16V
C611 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C612 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C613 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C614 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C615 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C616 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C617 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C618 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C619 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C620 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C621 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C622 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C623 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C629 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C630 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C701 1-126-933-11 ELECT 100µF 20% 16V
C702 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C703 1-126-933-11 ELECT 100µF 20% 16V
C704 1-126-933-11 ELECT 100µF 20% 16V
C705 1-126-933-11 ELECT 100µF 20% 16V
C706 1-126-933-11 ELECT 100µF 20% 16V
C711 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C712 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C713 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C714 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C715 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C716 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C717 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C718 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C719 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C720 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C722 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C723 1-163-038-91 CERAMIC CHIP 0.1µF 25V
<CONNECTOR>
CN1 1-694-600-11 TERMINAL BOARD ASSY, I/O
CN2 1-566-849-11 CONNECTOR, (S) TERMINAL 4P
CN3 * 1-793-303-11 CONNECTOR, ROUND TYPE (SVIDEO)
CN4 * 1-774-523-11 PIN, CONNECTOR (PC BOARD) 64P
<DIODE>
D1 8-719-073-01 DIODE MA111-(K8).S0
D11 8-719-073-01 DIODE MA111-(K8).S0
D21 8-719-073-01 DIODE MA111-(K8).S0
D31 8-719-073-01 DIODE MA111-(K8).S0
D261 8-719-073-01 DIODE MA111-(K8).S0
D264 8-719-073-01 DIODE MA111-(K8).S0
D301 8-719-002-81 DIODE 1T363
D321 8-719-045-70 DIODE 1SV230TPH3
D361 8-719-002-81 DIODE 1T363
D401 8-719-801-78 DIODE 1SS184
D421 8-719-073-01 DIODE MA111-(K8).S0
D424 8-719-073-01 DIODE MA111-(K8).S0
D471 8-719-073-01 DIODE MA111-(K8).S0
D474 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-158-19 DIODE RD6.2SB
D502 8-719-073-01 DIODE MA111-(K8).S0
BW
BKM-127W
