5-12
BKM-120D/127W/129X/142HD
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
<DELAY LINE>
DL201 1-411-457-11 DELAY LINE
DL202 1-402-770-11 DELAY LINE
DL221 1-411-451-11 DELAY LINE
<FILTER>
FL101 1-239-289-11 FILTER, LOW PASS
FL141 1-239-289-11 FILTER, LOW PASS
FL161 1-239-289-11 FILTER, LOW PASS
FL501 1-239-183-11 FILTER, EMI
FL551 1-239-480-11 FILTER, EMI
FL552 1-239-480-11 FILTER, EMI
<IC>
IC1 8-759-242-64 IC TC4W53F
IC11 8-759-242-64 IC TC4W53F
IC21 8-759-710-86 IC NJM2233BM
IC31 8-759-710-86 IC NJM2233BM
IC101 8-759-242-64 IC TC4W53F
IC121 8-752-372-78 IC CXD2024AQ
IC122 8-752-367-59 IC CXD2309Q
IC181 8-759-514-57 IC BA7046F
IC182 8-759-239-34 IC TC74HC4538AF
IC201 8-759-710-86 IC NJM2233BM
IC261 8-752-053-21 IC CXA1211M
IC301 8-759-631-08 IC M51279FP
IC302 8-759-710-86 IC NJM2233BM
IC361 8-759-983-69 IC LM358PS
IC401 8-759-565-20 IC TDA4665T/V5-118
IC402 8-759-710-86 IC NJM2233BM
IC421 8-752-053-21 IC CXA1211M
IC451 8-759-710-86 IC NJM2233BM
IC501 8-759-594-41 IC MB89613R-651
IC502 8-759-186-44 IC TC74VHC125F
IC503 8-759-156-54 IC X25040SI
IC504 8-759-064-36 IC MB88346BPFV
IC601 8-759-460-74 IC BA05FP-E2
IC701 8-759-539-89 IC LM2990SX-5.0
<COIL>
L1 1-216-295-91 SHORT 0
L2 1-216-295-91 SHORT 0
L11 1-216-295-91 SHORT 0
L12 1-216-295-91 SHORT 0
L121 1-410-470-11 INDUCTOR 10µH
<TRANSISTOR>
Q1 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q11 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q31 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q104 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q121 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q141 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q142 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q143 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q144 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q161 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q162 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q163 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q164 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q202 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q203 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q221 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q223 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q224 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q241 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q261 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q263 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q264 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q303 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q321 8-729-116-05 TRANSISTOR 2SK160-K5
Q322 8-729-116-05 TRANSISTOR 2SK160-K5
Q323 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q324 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q325 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q326 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q361 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q362 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q363 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q364 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q403 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q404 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q421 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q424 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q451 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q452 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q453 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q454 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q471 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q474 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q501 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q502 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q503 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q504 8-729-027-38 TRANSISTOR DTA144EKA-T146
<RESISTOR>
R1 1-214-837-11 METAL 75 1% 1/2W
R2 1-216-089-91 RES,CHIP 47K 5% 1/10W
R3 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R4 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R11 1-214-837-11 METAL 75 1% 1/2W
R12 1-216-089-91 RES,CHIP 47K 5% 1/10W
R13 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R14 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R21 1-214-837-11 METAL 75 1% 1/2W
R22 1-216-089-91 RES,CHIP 47K 5% 1/10W
R23 1-216-049-91 RES,CHIP 1K 5% 1/10W
R24 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R25 1-216-025-91 RES,CHIP 100 5% 1/10W
R26 1-216-025-91 RES,CHIP 100 5% 1/10W
R31 1-214-837-11 METAL 75 1% 1/2W
R32 1-216-089-91 RES,CHIP 47K 5% 1/10W
R33 1-216-049-91 RES,CHIP 1K 5% 1/10W
R34 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R35 1-216-025-91 RES,CHIP 100 5% 1/10W
R36 1-216-025-91 RES,CHIP 100 5% 1/10W
BW
BKM-127W
