– 74 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D008 8-719-200-82 DIODE 11ES2
D009 8-719-200-82 DIODE 11ES2
D011 8-719-200-82 DIODE 11ES2
D012 8-719-200-82 DIODE 11ES2
D013 8-719-200-82 DIODE 11ES2
D014 8-719-200-82 DIODE 11ES2
D017 8-719-200-82 DIODE 11ES2
D018 8-719-200-82 DIODE 11ES2
D024 8-719-200-82 DIODE 11ES2
D311 8-719-987-63 DIODE 1N4148M
D351 8-719-987-63 DIODE 1N4148M
D521 8-719-002-60 DIODE UZL-33L
D531 8-719-014-66 DIODE UZP-5.6B
< GROUND TERMINAL >
EP301 1-537-771-21 TERMINAL BOARD, GROUND
EP302 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB4 1-410-396-41 INDUCTOR, FERRITE BEAD
FB501 1-410-396-41 INDUCTOR, FERRITE BEAD
FB502 1-410-396-41 INDUCTOR, FERRITE BEAD
FB503 1-410-396-41 INDUCTOR, FERRITE BEAD
FB504 1-410-396-41 INDUCTOR, FERRITE BEAD
FB507 1-410-396-41 INDUCTOR, FERRITE BEAD
< IC >
IC101 8-759-434-43 IC CXA8065S
IC201 8-759-426-99 IC CXD8607N
IC301 8-749-012-70 IC GP1F38R
(MD DIGITAL OPTICAL DIGITAL IN CD PLAYER)
IC302 8-749-012-70 IC GP1F38R
(MD DIGITAL OPTICAL DIGITAL IN VIDEO 2)
IC303 8-759-917-18 IC SN74HCU04AN
IC304 8-759-916-12 IC SN74HC00AN
IC311 8-759-822-09 IC LB1641
IC401 8-759-456-21 IC RU8X12MF-0010
IC501 8-759-426-96 IC LA5620
IC541 8-759-708-06 IC NJM78L06A
IC551 8-759-700-69 IC NJM79L12A
< PIN JACK >
J101 1-770-720-11 JACK, PIN 4P (MD ANALOG IN/OUT)
< COIL >
L1 1-414-142-11 INDUCTOR 1uH
L2 1-414-142-11 INDUCTOR 1uH
L3 1-410-509-11 INDUCTOR 10uH
L5 1-410-324-11 INDUCTOR 4.7uH
L391 1-408-117-00 INDUCTOR 10uH
L392 1-408-117-00 INDUCTOR 10uH
< TRANSISTOR >
Q311 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q312 8-729-900-80 TRANSISTOR DTC114ES
Q351 8-729-620-05 TRANSISTOR 2SC2603-EF
Q454 8-729-422-57 TRANSISTOR UN4111
Q455 8-729-422-57 TRANSISTOR UN4111
Q456 8-729-422-57 TRANSISTOR UN4111
Q461 8-729-422-57 TRANSISTOR UN4111
Q501 8-729-900-80 TRANSISTOR DTC114ES
Q502 8-729-422-57 TRANSISTOR UN4111
Q521 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q522 8-729-118-01 TRANSISTOR 2SB1116
< RESISTOR >
R107 1-249-439-11 CARBON 68K 5% 1/4W
R108 1-249-439-11 CARBON 68K 5% 1/4W
R109 1-249-429-11 CARBON 10K 5% 1/4W
R110 1-249-421-11 CARBON 2.2K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W
R114 1-249-421-11 CARBON 2.2K 5% 1/4W
R115 1-249-429-11 CARBON 10K 5% 1/4W
R116 1-249-439-11 CARBON 68K 5% 1/4W
R117 1-249-439-11 CARBON 68K 5% 1/4W
R121 1-249-441-11 CARBON 100K 5% 1/4W
R123 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-433-11 CARBON 22K 5% 1/4W
R126 1-249-438-11 CARBON 56K 5% 1/4W
R127 1-249-429-11 CARBON 10K 5% 1/4W
R128 1-249-429-11 CARBON 10K 5% 1/4W
R129 1-249-438-11 CARBON 56K 5% 1/4W
R130 1-249-433-11 CARBON 22K 5% 1/4W
R131 1-249-429-11 CARBON 10K 5% 1/4W
R132 1-249-429-11 CARBON 10K 5% 1/4W
R134 1-249-441-11 CARBON 100K 5% 1/4W
R141 1-249-433-11 CARBON 22K 5% 1/4W
R142 1-249-433-11 CARBON 22K 5% 1/4W
R143 1-249-435-11 CARBON 33K 5% 1/4W
R144 1-249-435-11 CARBON 33K 5% 1/4W
R145 1-249-433-11 CARBON 22K 5% 1/4W
R146 1-249-433-11 CARBON 22K 5% 1/4W
R147 1-249-435-11 CARBON 33K 5% 1/4W
R148 1-249-435-11 CARBON 33K 5% 1/4W
R150 1-249-429-11 CARBON 10K 5% 1/4W
R151 1-249-437-11 CARBON 47K 5% 1/4W
R152 1-249-413-11 CARBON 470 5% 1/4W
R153 1-249-441-11 CARBON 100K 5% 1/4W
R160 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-249-437-11 CARBON 47K 5% 1/4W
R162 1-249-413-11 CARBON 470 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
R201 1-249-401-11 CARBON 47 5% 1/4W
R202 1-249-401-11 CARBON 47 5% 1/4W
R206 1-249-401-11 CARBON 47 5% 1/4W
R215 1-249-401-11 CARBON 47 5% 1/4W
R225 1-249-413-11 CARBON 470 5% 1/4W
R235 1-249-411-11 CARBON 330 5% 1/4W
R236 1-247-903-00 CARBON 1M 5% 1/4W
R252 1-249-401-11 CARBON 47 5% 1/4W
R253 1-249-401-11 CARBON 47 5% 1/4W
R255 1-249-401-11 CARBON 47 5% 1/4W
R256 1-249-401-11 CARBON 47 5% 1/4W
R301 1-247-895-00 CARBON 470K 5% 1/4W
MAIN
