Sony CDP-EX770 - Page 140

– 75 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R302 1-247-895-00 CARBON 470K 5% 1/4W
R303 1-249-437-11 CARBON 47K 5% 1/4W
R304 1-249-437-11 CARBON 47K 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R313 1-249-429-11 CARBON 10K 5% 1/4W
R316 1-249-403-11 CARBON 68 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R347 1-249-441-11 CARBON 100K 5% 1/4W
R351 1-249-429-11 CARBON 10K 5% 1/4W
R352 1-249-425-11 CARBON 4.7K 5% 1/4W
R353 1-249-429-11 CARBON 10K 5% 1/4W
R354 1-249-393-11 CARBON 10 5% 1/4W
R355 1-247-807-31 CARBON 100 5% 1/4W
R403 1-249-429-11 CARBON 10K 5% 1/4W
R404 1-249-429-11 CARBON 10K 5% 1/4W
R405 1-249-429-11 CARBON 10K 5% 1/4W
R406 1-249-429-11 CARBON 10K 5% 1/4W
R407 1-249-429-11 CARBON 10K 5% 1/4W
R408 1-249-429-11 CARBON 10K 5% 1/4W
R409 1-249-429-11 CARBON 10K 5% 1/4W
R427 1-247-903-00 CARBON 1M 5% 1/4W
R435 1-249-441-11 CARBON 100K 5% 1/4W
R436 1-249-429-11 CARBON 10K 5% 1/4W
R437 1-249-441-11 CARBON 100K 5% 1/4W
R438 1-249-441-11 CARBON 100K 5% 1/4W
R441 1-249-441-11 CARBON 100K 5% 1/4W
R442 1-249-441-11 CARBON 100K 5% 1/4W
R450 1-249-429-11 CARBON 10K 5% 1/4W
R451 1-249-429-11 CARBON 10K 5% 1/4W
R459 1-249-417-11 CARBON 1K 5% 1/4W
R462 1-249-441-11 CARBON 100K 5% 1/4W
R463 1-249-441-11 CARBON 100K 5% 1/4W
R467 1-249-429-11 CARBON 10K 5% 1/4W
R468 1-249-429-11 CARBON 10K 5% 1/4W
R469 1-249-429-11 CARBON 10K 5% 1/4W
R481 1-249-437-11 CARBON 47K 5% 1/4W
R483 1-249-437-11 CARBON 47K 5% 1/4W
R490 1-249-429-11 CARBON 10K 5% 1/4W
R494 1-249-441-11 CARBON 100K 5% 1/4W
R496 1-249-429-11 CARBON 10K 5% 1/4W
R497 1-249-429-11 CARBON 10K 5% 1/4W
R498 1-249-429-11 CARBON 10K 5% 1/4W
R509 1-249-429-11 CARBON 10K 5% 1/4W
R513 1-249-429-11 CARBON 10K 5% 1/4W
R514 1-249-429-11 CARBON 10K 5% 1/4W
R515 1-249-417-11 CARBON 1K 5% 1/4W
R516 1-247-807-31 CARBON 100 5% 1/4W
R521 1-249-393-11 CARBON 10 5% 1/4W
R522 1-249-425-11 CARBON 4.7K 5% 1/4W
R523 1-249-429-11 CARBON 10K 5% 1/4W
R531 1-249-413-11 CARBON 470 5% 1/4W
R532 1-249-413-11 CARBON 470 5% 1/4W
R533 1-249-441-11 CARBON 100K 5% 1/4W
¡ R540 1-247-702-11 CARBON 150 5% 1/4W F
¡ R541 1-247-702-11 CARBON 150 5% 1/4W F
¡ R542 1-247-702-11 CARBON 150 5% 1/4W F
¡ R543 1-247-702-11 CARBON 150 5% 1/4W F
¡ R544 1-247-702-11 CARBON 150 5% 1/4W F
¡ R545 1-247-702-11 CARBON 150 5% 1/4W F
¡ R546 1-247-702-11 CARBON 150 5% 1/4W F
¡ R547 1-247-702-11 CARBON 150 5% 1/4W F
¡ R548 1-247-702-11 CARBON 150 5% 1/4W F
¡ R549 1-247-702-11 CARBON 150 5% 1/4W F
< SWITCH >
S408 1-554-303-21 SWITCH, TACTILE (POWER)
< VIBRATOR >
X201 1-579-314-11 VIBRATOR, CRYSTAL (22MHz)
X401 1-567-098-61 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-767-157-21 VIBRATOR, CERAMIC (12MHz)
************************************************************
* A-4699-657-A PANEL BOARD, COMPLETE
**********************
1-690-880-51 LEAD (WITH CONNECTOR)
2-389-320-01 CUSHION
* 4-956-134-01 HOLDER (FL TUBE)
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C97 1-164-159-11 CERAMIC 0.1uF 50V
C701 1-164-159-11 CERAMIC 0.1uF 50V
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-126-791-11 ELECT 10uF 20% 35V
C705 1-162-282-31 CERAMIC 100PF 10% 50V
C706 1-162-282-31 CERAMIC 100PF 10% 50V
C707 1-162-282-31 CERAMIC 100PF 10% 50V
C708 1-162-282-31 CERAMIC 100PF 10% 50V
C709 1-162-282-31 CERAMIC 100PF 10% 50V
C710 1-162-282-31 CERAMIC 100PF 10% 50V
C711 1-162-282-31 CERAMIC 100PF 10% 50V
C712 1-162-282-31 CERAMIC 100PF 10% 50V
C713 1-162-282-31 CERAMIC 100PF 10% 50V
C714 1-162-282-31 CERAMIC 100PF 10% 50V
C715 1-162-282-31 CERAMIC 100PF 10% 50V
C716 1-162-282-31 CERAMIC 100PF 10% 50V
C717 1-162-282-31 CERAMIC 100PF 10% 50V
C718 1-162-282-31 CERAMIC 100PF 10% 50V
C719 1-162-282-31 CERAMIC 100PF 10% 50V
C720 1-162-282-31 CERAMIC 100PF 10% 50V
C721 1-162-282-31 CERAMIC 100PF 10% 50V
C722 1-162-282-31 CERAMIC 100PF 10% 50V
C723 1-162-282-31 CERAMIC 100PF 10% 50V
C724 1-162-282-31 CERAMIC 100PF 10% 50V
C725 1-162-282-31 CERAMIC 100PF 10% 50V
C726 1-162-282-31 CERAMIC 100PF 10% 50V
C741 1-162-282-31 CERAMIC 100PF 10% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
PANELMAIN
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
