– 76 –
C756 1-164-159-11 CERAMIC 0.1uF 50V
C758 1-162-215-31 CERAMIC 47PF 5% 50V
C760 1-162-294-31 CERAMIC 0.001uF 10% 50V
C761 1-162-294-31 CERAMIC 0.001uF 10% 50V
C762 1-162-294-31 CERAMIC 0.001uF 10% 50V
C763 1-162-294-31 CERAMIC 0.001uF 10% 50V
C764 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-778-449-11 CONNECTOR, FFC/FPC 19P
< LED >
D731 8-719-057-09 LED LNJ801LPDJA (= SELECTOR +)
D732 8-719-057-09 LED LNJ801LPDJA (ENTER/YES)
D733 8-719-058-17 LED LNG401NPYJA (ANALOG IN)
D734 8-719-058-17 LED LNG401NPYJA (32kHz)
D735 8-719-058-17 LED LNG401NPYJA (44.1kHz)
D736 8-719-058-17 LED LNG401NPYJA (48kHz)
< FERRITE BEAD >
FB1 1-410-396-41 INDUCTOR, FERRITE BEAD
< FLUORESCENT INDICATOR TUBE >
FL701 1-517-575-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 8-759-426-98 IC MSM9202-02GS-K
< TRANSISTOR >
Q701 8-729-422-57 TRANSISTOR UN4111
Q702 8-729-422-57 TRANSISTOR UN4111
Q703 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R702 1-249-421-11 CARBON 2.2K 5% 1/4W
R703 1-247-843-11 CARBON 3.3K 5% 1/4W
R704 1-249-425-11 CARBON 4.7K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-435-11 CARBON 33K 5% 1/4W
R712 1-249-421-11 CARBON 2.2K 5% 1/4W
R713 1-247-843-11 CARBON 3.3K 5% 1/4W
R714 1-249-431-11 CARBON 15K 5% 1/4W
R722 1-249-421-11 CARBON 2.2K 5% 1/4W
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W
R725 1-249-429-11 CARBON 10K 5% 1/4W
R726 1-249-435-11 CARBON 33K 5% 1/4W
R731 1-249-397-11 CARBON 22 5% 1/4W
R732 1-249-397-11 CARBON 22 5% 1/4W
R733 1-249-401-11 CARBON 47 5% 1/4W
R735 1-249-401-11 CARBON 47 5% 1/4W
R758 1-247-842-11 CARBON 3K 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-247-807-31 CARBON 100 5% 1/4W
R762 1-247-807-31 CARBON 100 5% 1/4W
R763 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-554-303-21 SWITCH, TACTILE (fl)
S702 1-554-303-21 SWITCH, TACTILE ())
S703 1-554-303-21 SWITCH, TACTILE (0)
S704 1-554-303-21 SWITCH, TACTILE (p)
S705 1-554-303-21 SWITCH, TACTILE (ENTER/YES)
S706 1-554-303-21 SWITCH, TACTILE (EDIT/NO)
S711 1-554-303-21 SWITCH, TACTILE (§ EJECT)
S712 1-554-303-21 SWITCH, TACTILE (PROGRAM)
S713 1-554-303-21 SWITCH, TACTILE (SHUFFLE)
S714 1-554-303-21 SWITCH, TACTILE (CONTINUE)
S722 1-554-303-21 SWITCH, TACTILE (SCROLL)
S723 1-554-303-21 SWITCH, TACTILE (DISPLAY/CHARACTER)
S724 1-554-303-21 SWITCH, TACTILE (REPEAT)
S725 1-554-303-21 SWITCH, TACTILE (CD SYNC)
S726 1-554-303-21 SWITCH, TACTILE (r REC)
S741 1-467-938-11 ENCODER, ROTARY (= SELECTOR +)
************************************************************
* 1-663-192-11 REC VOL BOARD
**************
< CONNECTOR >
* CN801 1-568-848-11 SOCKET, CONNECTOR 5P
< VARIABLE RESISTOR >
RV801 1-225-417-11 RES, VAR, CARBON 20k×2 (REC LEVEL)
************************************************************
* 1-661-774-11 SW BOARD
*********
< CONNECTOR >
CN601 1-770-698-11 CONNECTOR, FFC/FPC 15P
CN602 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
CN603 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
S681 1-572-467-61 SWITCH, PUSH (1 KEY) (LIMIT IN)
S682 1-692-377-31 SWITCH, PUSH (1 KEY) (REFLECT)
S683 1-692-847-21 SWITCH, PUSH (1 KEY) (PROTECT)
S685 1-572-467-61 SWITCH, PUSH (1 KEY) (CHUCKING IN)
S686 1-762-621-21 SWITCH, PUSH (1 KEY) (PACK OUT)
S687 1-572-688-11 SWITCH, PUSH (1 KEY) (PB POSITION)
S688 1-762-621-21 SWITCH, PUSH (1 KEY) (REC POSITION)
************************************************************
MISCELLANEOUS
**************
10 1-777-654-11 WIRE (FLAT TYPE) (19 CORE)
PANEL REC VOL SW
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
