– 77 –
11 1-777-558-11 WIRE (FLAT TYPE) (19 CORE)
12 1-777-559-11 WIRE (FLAT TYPE) (29 CORE)
20 1-777-473-11 WIRE (FLAT TYPE) (5 CORE)
56 1-660-966-11 OP RELAY FLEXIBLE BOARD
58 1-777-517-11 WIRE (FLAT TYPE) (15 CORE)
¡ 117 8-583-028-02 OPTICAL PICK-UP KMS-260A/J1N
HR901 1-500-396-11 HEAD, OVER WRITE
M901 A-4672-135-A MOTOR ASSY, SPINDLE
M902 A-4672-133-A MOTOR ASSY, SLED
M903 A-4672-134-A MOTOR ASSY, LOADING
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-850-04 SCREW +BVTT 2X3 (S)
#3 7-627-553-17 PRECISION SCREW +P 2X2 TYPE 3
#4 7-627-552-27 SCREW, PRECISION +P 1.7X2
#5 7-685-851-04 SCREW +BVTT 2X4 (S)
#6 7-685-871-01 SCREW +BVTT 3X6 (S)
#7 7-627-852-28 +P 1.7X3
Ref. No. Part No. Description Remark
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
