– 26 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< IC >
IC1 8-759-176-03 IC LA1835
IC51 8-759-288-54 IC LC72130
IC111 8-759-231-53 IC TA7805S
IC171 8-759-165-80 IC PST600C-T
IC201 8-759-467-14 IC uPD78013FGC-544-AB8
IC301 8-759-634-51 IC M5218AP (AEP, UK)
IC302 8-759-169-99 IC SAA6579 (AEP, UK)
< IFT >
IFT1 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JACK >
J101 1-770-272-11 JACK, PIN 2P (TUNER OUT)
< COIL >
L1 1-407-500-00 INDUCTOR 4.7mH (AEP, UK)
L1 1-410-688-31 INDUCTOR 1.5mH (HK, SP)
L3 1-410-470-11 INDUCTOR 10uH
L4 1-410-509-11 INDUCTOR 10uH
L7 1-410-397-21 FERRITE BEAD INDUCTOR
L10 1-410-470-11 INDUCTOR 10uH (AEP, UK)
L11 1-410-324-11 INDUCTOR 4.7uH
L13 1-410-324-11 INDUCTOR 4.7uH
L101 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L102 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L103 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L104 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L108 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L109 1-410-397-21 FERRITE BEAD INDUCTOR (AEP, UK)
L201 1-410-482-31 INDUCTOR 100uH
L202 1-410-482-31 INDUCTOR 100uH
L203 1-410-521-11 INDUCTOR 100uH
L204 1-410-521-11 INDUCTOR 100uH
L205 1-410-521-11 INDUCTOR 100uH
L206 1-410-521-11 INDUCTOR 100uH
L207 1-410-521-11 INDUCTOR 100uH
L208 1-410-521-11 INDUCTOR 100uH
< FILTER >
LPF1 1-239-597-11 FILTER, LOW PASS
LPF2 1-239-597-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-230-99 TRANSISTOR 2SC2669-OY
Q2 8-729-230-99 TRANSISTOR 2SC2669-OY
Q9 8-729-230-99 TRANSISTOR 2SC2669-OY
Q10 8-729-230-99 TRANSISTOR 2SC2669-OY
Q11 8-729-900-80 TRANSISTOR DTC114ES (AEP, UK)
Q12 8-729-900-80 TRANSISTOR DTC114ES (AEP, UK)
Q13 8-729-900-80 TRANSISTOR DTC114ES (AEP, UK)
Q14 8-729-900-80 TRANSISTOR DTC114ES (AEP, UK)
Q15 8-729-119-76 TRANSISTOR 2SA1175-HFE (AEP, UK)
Q55 8-729-422-57 TRANSISTOR UN4111
Q121 8-729-202-67 TRANSISTOR 2SK246-GR3
Q122 8-729-209-15 TRANSISTOR 2SD2012
Q123 8-729-900-80 TRANSISTOR DTC114ES
Q141 8-729-118-00 TRANSISTOR 2SB1116-L
Q142 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q201 8-729-900-80 TRANSISTOR DTC114ES
Q271 8-729-422-57 TRANSISTOR UN4111
Q272 8-729-900-80 TRANSISTOR DTC114ES
Q281 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R1 1-249-411-11 CARBON 330 5% 1/4W
R2 1-249-411-11 CARBON 330 5% 1/4W
R3 1-249-409-11 CARBON 220 5% 1/4W
¡R4 1-249-402-11 CARBON 56 5% 1/4W F
R5 1-249-411-11 CARBON 330 5% 1/4W
R6 1-249-411-11 CARBON 330 5% 1/4W
R7 1-249-432-11 CARBON 18K 5% 1/4W
R8 1-249-432-11 CARBON 18K 5% 1/4W
R11 1-249-411-11 CARBON 330 5% 1/4W
R12 1-249-429-11 CARBON 10K 5% 1/4W
R13 1-249-442-11 CARBON 510 5% 1/4W
¡R14 1-249-403-11 CARBON 68 5% 1/4W F
R15 1-249-411-11 CARBON 330 5% 1/4W
R16 1-249-425-11 CARBON 4.7K 5% 1/4W
R17 1-247-842-11 CARBON 3K 5% 1/4W
R18 1-249-429-11 CARBON 10K 5% 1/4W
R19 1-249-429-11 CARBON 10K 5% 1/4W
R21 1-249-429-11 CARBON 10K 5% 1/4W
R22 1-249-437-11 CARBON 47K 5% 1/4W
R23 1-249-399-11 CARBON 33 5% 1/4W
R24 1-249-425-11 CARBON 4.7K 5% 1/4W
(AEP, UK)
R25 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R28 1-249-432-11 CARBON 18K 5% 1/4W
R29 1-249-411-11 CARBON 330 5% 1/4W
R35 1-249-421-11 CARBON 2.2K 5% 1/4W
R36 1-249-421-11 CARBON 2.2K 5% 1/4W
R37 1-249-411-11 CARBON 330 5% 1/4W
R38 1-249-432-11 CARBON 18K 5% 1/4W
R39 1-249-393-11 CARBON 10 5% 1/4W
(AEP, UK)
R39 1-249-401-11 CARBON 47 5% 1/4W
(HK, SP)
R45 1-249-425-11 CARBON 4.7K 5% 1/4W
R46 1-249-425-11 CARBON 4.7K 5% 1/4W
R49 1-249-441-11 CARBON 100K 5% 1/4W
R51 1-249-429-11 CARBON 10K 5% 1/4W
R56 1-249-417-11 CARBON 1K 5% 1/4W
R58 1-249-417-11 CARBON 1K 5% 1/4W
¡R60 1-249-405-11 CARBON 100 5% 1/4W F
R61 1-247-843-11 CARBON 3.3K 5% 1/4W
R62 1-249-425-11 CARBON 4.7K 5% 1/4W
R63 1-249-425-11 CARBON 4.7K 5% 1/4W
MAIN
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number speci-
fied.
