– 27 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R64 1-249-425-11 CARBON 4.7K 5% 1/4W
R65 1-249-425-11 CARBON 4.7K 5% 1/4W
R70 1-249-425-11 CARBON 4.7K 5% 1/4W
(AEP, UK)
R71 1-249-425-11 CARBON 4.7K 5% 1/4W
R72 1-247-807-31 CARBON 100 5% 1/4W
R122 1-247-807-31 CARBON 100 5% 1/4W
R141 1-249-429-11 CARBON 10K 5% 1/4W
R142 1-249-441-11 CARBON 100K 5% 1/4W
R143 1-249-397-11 CARBON 22 5% 1/4W
R161 1-249-441-11 CARBON 100K 5% 1/4W
R162 1-249-413-11 CARBON 470 5% 1/4W
R163 1-249-413-11 CARBON 470 5% 1/4W
R171 1-249-417-11 CARBON 1K 5% 1/4W
R181 1-247-807-31 CARBON 100 5% 1/4W
R191 1-249-411-11 CARBON 330 5% 1/4W
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W
R203 1-249-417-11 CARBON 1K 5% 1/4W
R204 1-247-807-31 CARBON 100 5% 1/4W
R205 1-249-417-11 CARBON 1K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
R207 1-249-412-11 CARBON 390 5% 1/4W
R208 1-249-414-11 CARBON 560 5% 1/4W
R209 1-249-412-11 CARBON 390 5% 1/4W
R212 1-249-417-11 CARBON 1K 5% 1/4W
R213 1-249-417-11 CARBON 1K 5% 1/4W
R214 1-249-417-11 CARBON 1K 5% 1/4W
R215 1-249-417-11 CARBON 1K 5% 1/4W
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-429-11 CARBON 10K 5% 1/4W
R222 1-247-893-11 CARBON 390K 5% 1/4W
R224 1-247-843-11 CARBON 3.3K 5% 1/4W
R225 1-247-843-11 CARBON 3.3K 5% 1/4W
R226 1-247-843-11 CARBON 3.3K 5% 1/4W
R227 1-249-441-11 CARBON 100K 5% 1/4W
R228 1-249-441-11 CARBON 100K 5% 1/4W
R229 1-247-807-31 CARBON 100 5% 1/4W
R230 1-247-807-31 CARBON 100 5% 1/4W
R231 1-249-425-11 CARBON 4.7K 5% 1/4W
R271 1-249-429-11 CARBON 10K 5% 1/4W
R281 1-249-429-11 CARBON 10K 5% 1/4W
R282 1-249-425-11 CARBON 4.7K 5% 1/4W
R283 1-249-393-11 CARBON 10 5% 1/4W
R284 1-249-429-11 CARBON 10K 5% 1/4W
R285 1-249-393-11 CARBON 10 5% 1/4W
R301 1-249-441-11 CARBON 100K 5% 1/4W
(AEP, UK)
R302 1-249-441-11 CARBON 100K 5% 1/4W
(AEP, UK)
R303 1-249-441-11 CARBON 100K 5% 1/4W
(AEP, UK)
R304 1-249-441-11 CARBON 100K 5% 1/4W
(AEP, UK)
R305 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R306 1-249-426-11 CARBON 5.6K 5% 1/4W
(AEP, UK)
R308 1-249-421-11 CARBON 2.2K 5% 1/4W
(AEP, UK)
< VARIABLE RESISTOR >
RV1 1-238-601-11 RES, ADJ, CARBON 22.0K
RV2 1-238-600-11 RES, ADJ, CARBON 10.0K
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (FM/AM ANTENNA)
(HK, SP)
TM1 1-537-488-11 TERMINAL BOARD (ANT) (FM/AM ANTENNA)
(AEP, UK)
< VIBRATOR >
X201 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X202 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X301 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
XT51 1-760-549-31 VIBRATOR, CRYSTAL (4.5MHz)
************************************************************
* A-4398-065-A PANEL BOARD, COMPLETE (AEP, UK)
* A-4398-070-A PANEL BOARD, COMPLETE (HK, SP)
*********************
* 4-970-787-11 HOLDER (FL)
< CAPACITOR >
C601 1-124-584-00 ELECT 100uF 20% 10V
C602 1-164-159-11 CERAMIC 0.1uF 50V
C603 1-124-248-00 ELECT 22uF 20% 35V
C604 1-164-159-11 CERAMIC 0.1uF 50V
C605 1-162-282-31 CERAMIC 100PF 10% 50V
C606 1-162-282-31 CERAMIC 100PF 10% 50V
C607 1-162-282-31 CERAMIC 100PF 10% 50V
C608 1-162-282-31 CERAMIC 100PF 10% 50V
C609 1-162-294-31 CERAMIC 0.001uF 10% 50V
C610 1-162-282-31 CERAMIC 100PF 10% 50V
C611 1-162-282-31 CERAMIC 100PF 10% 50V
C612 1-162-282-31 CERAMIC 100PF 10% 50V
C613 1-162-282-31 CERAMIC 100PF 10% 50V
C614 1-162-282-31 CERAMIC 100PF 10% 50V
C615 1-162-282-31 CERAMIC 100PF 10% 50V
C616 1-162-282-31 CERAMIC 100PF 10% 50V
C617 1-162-282-31 CERAMIC 100PF 10% 50V
C618 1-162-282-31 CERAMIC 100PF 10% 50V
C619 1-162-282-31 CERAMIC 100PF 10% 50V
C620 1-162-282-31 CERAMIC 100PF 10% 50V
C621 1-162-282-31 CERAMIC 100PF 10% 50V
C622 1-162-282-31 CERAMIC 100PF 10% 50V
C623 1-162-282-31 CERAMIC 100PF 10% 50V
C624 1-162-282-31 CERAMIC 100PF 10% 50V
C625 1-136-173-00 FILM 0.47uF 5% 50V
C626 1-136-173-00 FILM 0.47uF 5% 50V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN601 1-695-380-31 PIN, CONNECTOR (PC BOARD) 19P
< DIODE >
D601 8-719-057-09 DIODE LNJ801LPDJA (ENTER/NEXT)
D602 8-719-057-09 DIODE LNJ801LPDJA (MULTI CONTROLLER)
D603 8-719-057-10 DIODE LNJ301MPUJAB (SLEEP)
PANELMAIN
