— 30 —
• Abbreviation
FL : Fluorescent indicator tube
Pin No. Pin Name I/O Function
41 VSS – Ground
42 TX – Not used
43 TEX – Connected to ground
44 VDD (+5V) – Power supply (+5V)
45 VFDP (–30V) – Pull down voltage (–30V)
46 XSEL O Not used
47 — – Not used
48 LP CONTROL O LP control hold output
49 to 66 OPEN – Not used
67 to 87 S21 to S1 O FL segment signal output
88 1G O FL grid signal output
89 VDD (+5V) – Power supply (+5V)
90 to 100 2G to 12G O FL grid signal output
