Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 41 —
< IC >
IC601 8-759-061-65 IC LA5602
IC602 8-749-011-78 IC BA17807T
IC631 8-759-822-09 IC LB1641
IC651 8-749-921-12 IC GP1F32T(DIGITAL OUT OPTICAL)
IC661 8-759-362-47 IC CXD8567AM
IC671 8-759-604-86 IC M5F7807L
IC672 8-759-604-90 IC M5F7907L
IC681 8-759-634-51 IC M5218AP
IC801 8-759-710-59 IC NJM4580D-D
IC901 8-759-710-59 IC NJM4580D-D
< JACK >
J621 1-774-726-11 JACK(S-LINK CONTROL A1)
J681 1-785-868-11 JACK, PIN 2P(LINE OUT)
< COIL >
L640 1-410-507-11 INDUCTOR 6.8uH
L651 1-410-507-11 INDUCTOR 6.8uH
L652 1-410-322-11 INDUCTOR 3.3uH
L653 1-410-322-11 INDUCTOR 3.3uH
L654 1-412-473-21 INDUCTOR 0uH
L661 1-410-322-11 INDUCTOR 3.3uH
L662 1-410-322-11 INDUCTOR 3.3uH
L665 1-412-473-21 INDUCTOR 0uH
L801 1-410-322-11 INDUCTOR 3.3uH
L901 1-410-322-11 INDUCTOR 3.3uH
< TRANSISTOR >
Q621 8-729-620-05 TRANSISTOR 2SC2603-EF
Q641 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q642 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q681 8-729-029-56 TRANSISTOR DTA144ESA
Q682 8-729-922-37 TRANSISTOR 2SD2144S
Q683 8-729-922-37 TRANSISTOR 2SD2144S
Q691 8-729-029-56 TRANSISTOR DTA144ESA
Q692 8-729-922-37 TRANSISTOR 2SD2144S
Q693 8-729-922-37 TRANSISTOR 2SD2144S
< RESISTOR >
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-411-11 CARBON 330 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
R624 1-249-393-11 CARBON 10 5% 1/4W F
R625 1-249-429-11 CARBON 10K 5% 1/4W
R626 1-249-425-11 CARBON 4.7K 5% 1/4W F
R631 1-249-427-11 CARBON 6.8K 5% 1/4W F
R641 1-249-432-11 CARBON 18K 5% 1/4W
R642 1-249-432-11 CARBON 18K 5% 1/4W
R643 1-249-441-11 CARBON 100K 5% 1/4W
R644 1-249-441-11 CARBON 100K 5% 1/4W
R645 1-249-425-11 CARBON 4.7K 5% 1/4W F
R646 1-249-432-11 CARBON 18K 5% 1/4W
R647 1-247-807-31 CARBON 100 5% 1/4W
R648 1-247-807-31 CARBON 100 5% 1/4W
R651 1-249-429-11 CARBON 10K 5% 1/4W
R661 1-249-417-11 CARBON 1K 5% 1/4W F
R662 1-249-417-11 CARBON 1K 5% 1/4W F
R663 1-249-417-11 CARBON 1K 5% 1/4W F
R664 1-249-409-11 CARBON 220 5% 1/4W F
R665 1-247-807-31 CARBON 100 5% 1/4W
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-247-807-31 CARBON 100 5% 1/4W
R668 1-249-417-11 CARBON 1K 5% 1/4W F
R669 1-249-429-11 CARBON 10K 5% 1/4W
R671 1-249-424-11 CARBON 3.9K 5% 1/4W F
R672 1-249-401-11 CARBON 47 5% 1/4W F
R673 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-441-11 CARBON 100K 5% 1/4W
R682 1-249-419-11 CARBON 1.5K 5% 1/4W F
R683 1-249-419-11 CARBON 1.5K 5% 1/4W F
R691 1-249-441-11 CARBON 100K 5% 1/4W
R692 1-249-419-11 CARBON 1.5K 5% 1/4W F
R693 1-249-419-11 CARBON 1.5K 5% 1/4W F
R801 1-249-436-11 CARBON 39K 5% 1/4W
R802 1-249-436-11 CARBON 39K 5% 1/4W
R803 1-249-431-11 CARBON 15K 5% 1/4W
R804 1-249-431-11 CARBON 15K 5% 1/4W
R805 1-249-437-11 CARBON 47K 5% 1/4W
R806 1-249-437-11 CARBON 47K 5% 1/4W
R807 1-249-419-11 CARBON 1.5K 5% 1/4W F
R808 1-249-419-11 CARBON 1.5K 5% 1/4W F
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-414-11 CARBON 560 5% 1/4W F
R812 1-247-807-31 CARBON 100 5% 1/4W
R821 1-249-403-11 CARBON 68 5% 1/4W F
R901 1-249-436-11 CARBON 39K 5% 1/4W
R902 1-249-436-11 CARBON 39K 5% 1/4W
R903 1-249-431-11 CARBON 15K 5% 1/4W
R904 1-249-431-11 CARBON 15K 5% 1/4W
R905 1-249-437-11 CARBON 47K 5% 1/4W
R906 1-249-437-11 CARBON 47K 5% 1/4W
R907 1-249-419-11 CARBON 1.5K 5% 1/4W F
R908 1-249-419-11 CARBON 1.5K 5% 1/4W F
R909 1-249-441-11 CARBON 100K 5% 1/4W
R910 1-249-414-11 CARBON 560 5% 1/4W F
R912 1-247-807-31 CARBON 100 5% 1/4W
R921 1-249-403-11 CARBON 68 5% 1/4W F
< TRANSFORMER >
! T601 1-431-696-21 TRANSFORMER, POWER
< VIBRATOR >
X671 1-579-834-11 VIBRATOR, CRYSTAL 33MHz
************************************************************
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
MAIN
