— 33 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R818 1-249-429-11 CARBON 10K 5% 1/4W
R819 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (ENTER)
S802 1-554-303-21 SWITCH, TACTILE (CLEAR)
S803 1-554-303-21 SWITCH, TACTILE (CHECK)
S804 1-554-303-21 SWITCH, TACTILE (+)
S805 1-554-303-21 SWITCH, TACTILE (=)
S806 1-554-303-21 SWITCH, TACTILE (p)
S807 1-554-303-21 SWITCH, TACTILE (P)
S808 1-554-303-21 SWITCH, TACTILE (()
S809 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S810 1-473-452-11 ENCODER, ROTARY (≠ AMS ±)
< VIBRATOR >
X801 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
(XE900/XE900E:UK)
X801 1-577-358-21 VIBRATOR, CERAMIC (XE900E:CH)
**************************************************************
* 1-659-495-11 HP BOARD (XE900)
****************
* 4-962-201-01 PLATE (HP), GROUND
< CAPACITOR >
C350 1-162-294-31 CERAMIC 0.001uF 10% 50V
C351 1-162-294-31 CERAMIC 0.001uF 10% 50V
C352 1-164-159-21 CERAMIC 0.1uF 50V
< JACK >
J350 1-750-162-61 JACK (LARGE TYPE)(PHONES)
< COIL >
L350 1-410-507-11 INDUCTOR 6.8uH
L351 1-410-507-11 INDUCTOR 6.8uH
L352 1-412-473-41 INDUCTOR 0uH
< VARIABLE RESISTOR >
RV350 1-223-926-11 RES, VAR, CARBON 1K/1K
(LINE OUT, PHONE LEVEL)
**************************************************************
* 1-659-493-11 KEY BOARD
*********
< RESISTOR >
R820 1-249-415-11 CARBON 680 5% 1/4W F
R821 1-249-417-11 CARBON 1K 5% 1/4W F
R822 1-249-421-11 CARBON 2.2K 5% 1/4W F
R823 1-247-843-11 CARBON 3.3K 5% 1/4W
R824 1-249-427-11 CARBON 6.8K 5% 1/4W F
R825 1-249-431-11 CARBON 15K 5% 1/4W
R826 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S820 1-554-303-21 SWITCH, TACTILE (TIME)
S821 1-554-303-21 SWITCH, TACTILE (FADER)
S822 1-554-303-21 SWITCH, TACTILE (REPEAT)
S823 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S824 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S825 1-554-303-21 SWITCH, TACTILE (AUTO SPACE)
S826 1-554-303-21 SWITCH, TACTILE (MUSIC SCAN)
S827 1-554-118-00 SWITCH, PUSH (1 KEY)(POWER)
S828 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
**************************************************************
* 1-658-710-11 LOADING BOARD
*************
< MOTOR >
M151 A-4660-968-A MOTOR ASSY (LOADING)
**************************************************************
* A-4673-833-A MAIN BOARD, COMPLETE (XE900E:CH)
********************
* A-4673-836-A MAIN BOARD, COMPLETE (XE900)
********************
* A-4673-967-A MAIN BOARD, COMPLETE (XE900E:UK)
********************
* 3-309-144-21 HEAT SINK
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-161-494-00 CERAMIC 0.022uF 25V
C303 1-162-306-11 CERAMIC 0.01uF 30% 16V
C304 1-161-494-00 CERAMIC 0.022uF 25V
C305 1-164-159-11 CERAMIC 0.1uF 50V
(XE900E:CH)
C305 1-164-159-21 CERAMIC 0.1uF 50V
(XE900/XE900E:UK)
C306 1-126-962-11 ELECT 3.3uF 20% 50V
C308 1-126-059-11 ELECT 10uF 20% 50V
