— 35 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
* CN301 1-568-839-11 SOCKET, CONNECTOR 23P
CN301 1-750-428-11 CONNECTOR, FFC/FPC 23P
* CN302 1-568-839-11 SOCKET, CONNECTOR 23P
CN302 1-750-428-11 CONNECTOR, FFC/FPC 23P
CN351 1-506-468-11 PIN, CONNECTOR 3P (XE900)
CN951 1-766-269-11 PIN, CONNECTOR (PC BOARD) 7P
< DIODE >
D301 8-719-010-34 DIODE UZ-4.7BSC (XE900/XE900E:UK)
D301 8-719-109-81 DIODE RD4.7ESB2 (XE900E:CH)
D302 8-719-815-85 DIODE 1S1585 (XE900/XE900E:UK)
D302 8-719-987-63 DIODE 1N4148M (XE900E:CH)
D303 8-719-815-85 DIODE 1S1585 (XE900/XE900E:UK)
D303 8-719-987-63 DIODE 1N4148M (XE900E:CH)
D911 8-719-815-85 DIODE 1S1585 (XE900/XE900E:UK)
D911 8-719-987-63 DIODE 1N4148M (XE900E:CH)
D912 8-719-113-76 DIODE RD27ES-T2B2 (XE900E:CH)
D912 8-719-982-15 DIODE MTZJ-27B (XE900/XE900E:UK)
D913 8-719-110-03 DIODE RD7.5ESB2 (XE900/XE900E:UK)
D913 8-719-110-04 DIODE RD7.5ES-B3 (XE900E:CH)
D934 8-719-815-85 DIODE 1S1585 (XE900/XE900E:UK)
D934 8-719-987-63 DIODE 1N4148M (XE900E:CH)
D935 8-719-109-82 DIODE RD4.7ES-B3 (XE900E:CH)
D935 8-719-921-40 DIODE MTZJ-4.7C (XE900/XE900E:UK)
D936 8-719-815-85 DIODE 1S1585 (XE900/XE900E:UK)
D936 8-719-987-63 DIODE 1N4148M (XE900E:CH)
D937 8-719-114-30 DIODE RD5.1JS-B2 (XE900E:CH)
D937 8-719-115-38 DIODE RD5.1JS-T1B2 (XE900/XE900E:UK)
< GROUND TERMINAL >
* EB602 1-537-738-21 TERMINAL, EARTH (XE900/XE900E:UK)
EB602 1-537-770-21 TERMINAL BOARD, GROUND (XE900E:CH)
< IC >
IC301 8-759-822-09 IC LB1641
IC302 8-759-361-58 IC CXA8055M
IC303 8-759-370-62 IC CXD8505BQ
IC304 8-759-710-59 IC NJM4580D-D (XE900)
IC305 8-749-921-12 IC GP1F32T (OPTICAL DIGITAL OUT)
IC401 8-759-712-02 IC NJM2114D
IC402 8-759-602-83 IC M5238P
IC501 8-759-712-02 IC NJM2114D
IC502 8-759-602-83 IC M5238P
IC920 8-759-636-16 IC M51957AL
IC930 8-759-710-59 IC NJM4580D-D
IC931 8-759-710-59 IC NJM4580D-D
< JACK >
J301 1-774-727-11 JACK, PIN 2P (LINE OUT)
< COIL >
L301 1-410-322-11 INDUCTOR 3.3uH
L302 1-410-322-11 INDUCTOR 3.3uH
L303 1-410-503-11 INDUCTOR 3.3uH
L304 1-410-507-11 INDUCTOR 6.8uH
L353 1-410-397-21 FERRITE BEAD INDUCTOR (XE900)
< IC LINK >
PS901 1-532-835-21 LINK, IC
PS902 1-532-685-00 LINK, IC
PS903 1-532-679-00 LINK, IC
PS904 1-532-679-00 LINK, IC
< TRANSISTOR >
Q301 8-729-029-56 TRANSISTOR DTA144ESA
Q302 8-729-029-56 TRANSISTOR DTA144ESA (XE900)
Q303 8-729-029-56 TRANSISTOR DTA144ESA (XE900)
Q401 8-729-231-55 TRANSISTOR 2SC2878-AB
Q402 8-729-231-55 TRANSISTOR 2SC2878-AB (XE900)
Q501 8-729-231-55 TRANSISTOR 2SC2878-AB
Q502 8-729-231-55 TRANSISTOR 2SC2878-AB (XE900)
Q910 8-729-019-64 TRANSISTOR 2SB1041
Q911 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q920 8-729-030-03 TRANSISTOR DTC144ESA-TP
Q930 8-729-141-58 TRANSISTOR 2SC2275A-QP
Q931 8-729-030-03 TRANSISTOR DTC144ESA-TP
Q932 8-729-029-56 TRANSISTOR DTA144ESA
Q933 8-729-809-29 TRANSISTOR 2SC4159-E
Q934 8-729-021-82 TRANSISTOR 2SD2396K
Q935 8-729-141-10 TRANSISTOR 2SA985A-QP
Q936 8-729-224-62 TRANSISTOR 2SK246-GR
< RESISTOR >
R301 1-249-417-11 CARBON 1K 5% 1/4W F
R302 1-249-417-11 CARBON 1K 5% 1/4W F
R303 1-249-417-11 CARBON 1K 5% 1/4W F
R304 1-249-417-11 CARBON 1K 5% 1/4W F
R306 1-247-895-00 CARBON 470K 5% 1/4W
(XE900E:CH)
R306 1-247-895-91 CARBON 470K 5% 1/4W
(XE900/XE900E:UK)
R308 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-417-11 CARBON 1K 5% 1/4W F
R313 1-249-411-11 CARBON 330 5% 1/4W
R314 1-247-843-11 CARBON 3.3K 5% 1/4W
R317 1-249-441-11 CARBON 100K 5% 1/4W
R318 1-249-441-11 CARBON 100K 5% 1/4W
(XE900)
R319 1-249-441-11 CARBON 100K 5% 1/4W
(XE900)
R362 1-249-415-11 CARBON 680 5% 1/4W F
R405 1-249-461-11 CARBON 18K 5% 1/4W
