CDX-91/01RF
SERVICE MANUAL eres iene
AEP Model
UK Model
E Model
SUPPLEMENT-2
File this supplement with the service manual.
Subject:
1. Correction
2. Mechanism Deck Modification
3. Board Modification
(SPM-95046, ENG-96018)
TABLE OF CONTENTS
1. CORRECTION --- 2
2. MECHANISM DECK MODIFICATION
2-1. New/Former Discrimination - 2
2-2. Disassembly 3
2-3. Exploded Views - 4
3. BOARD MODIFICATION
3-1. New/Former Discrimination --- 9
3-2. Electrical Adjustments 9
3-3. Compact Disc Changer Section
Block Diagram ----
3-4. Compact Disc Changer Section
Printed Wiring Boards --
3-5. Compact Disc Changer Section
Schematic Diagram 19
3-6. IC Pin Function Description + 25
3-7. Exploded View “27
3-8. Electrical Parts List -- + 28
