Note: Follow the disassembly procedure in the numerical order given.
Note: Screws and washers cannot be re-used.
Please replace to brand-new ones once screws and washers are removed.
2-2. COVER (UP)
2-3. FRONT PANEL SECTION
1
two screws
(PTT2.6
×
6
1
two screws
(PTT2.6
×
6)
3
Remove the cover (up)
in the direction of the arrow.
2
two bosses
1
screw
(2
×
4.5)
1
screw
(2
×
4.5)
1
screw
(2
×
4.5)
1
screw
(2
×
4.5)
4
front panel section
2
two claws
2
two claws
3
key flexible board
(CN1)
