65
CDX-5V661/5V661A/5V661D/5V661S
ASSIST F1 F2
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3340-088-A ASSIST BOARD, COMPLETE
***********************
For the parts on the ASSIST board, replace the entire mounted board.
**************************************************************
* 1-680-572-11 F1 BOARD
*********
< CAPACITOR >
C181 1-137-894-11 ELECT CHIP 470uF 20% 25V
C182 1-137-894-11 ELECT CHIP 470uF 20% 25V
C183 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C186 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C187 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C188 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C190 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
* CN181 1-564-712-11 PIN, CONNECTOR (SMALL TYPE)10P
* CN182 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CN183 1-764-519-11 CONNECTOR, FFC/FPC (ZIF) 10P
< DIODE >
D181 8-719-073-92 DIODE RB060L-40TE25
D182 8-719-057-00 DIODE UDZ-TE-17-36B
D183 8-719-057-00 DIODE UDZ-TE-17-36B
D184 8-719-977-28 DIODE UDZSTE-1710B
D185 8-719-977-28 DIODE UDZSTE-1710B
D186 8-719-977-28 DIODE UDZSTE-1710B
D187 8-719-977-28 DIODE UDZSTE-1710B
D188 8-719-977-28 DIODE UDZSTE-1710B
D189 8-719-977-28 DIODE UDZSTE-1710B
D190 8-719-977-28 DIODE UDZSTE-1710B
< FERRITE BEAD >
FB181 1-414-444-11 FERRITE 0uH
FB182 1-414-444-11 FERRITE 0uH
FB183 1-414-444-11 FERRITE 0uH
< COIL >
L181 1-411-501-11 INDUCTOR 180uH
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
< RESISTOR >
R181 1-216-801-11 METAL CHIP 22 5% 1/16W
R182 1-216-801-11 METAL CHIP 22 5% 1/16W
R183 1-216-833-11 METAL CHIP 10K 5% 1/16W
< VARISTOR >
VDR181 1-801-066-21 VARISTOR ERZV07D220
**************************************************************
* A-3326-744-A F2 BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-137-892-11 ELECT 100uF 20% 25V
C102 1-137-892-11 ELECT 100uF 20% 25V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-135-474-21 ELECT 330uF 20% 6.3V
C106 1-165-505-11 DOUBLE LAYER 0.047PF 5.5V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C122 1-137-893-11 ELECT 22uF 20% 16V
C141 1-137-892-11 ELECT 100uF 20% 25V
C142 1-137-892-11 ELECT 100uF 20% 25V
C144 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C146 1-135-474-21 ELECT 330uF 20% 6.3V
C147 1-135-474-21 ELECT 330uF 20% 6.3V
C148 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C149 1-137-689-11 TANTALUM CHIP 47uF 20% 16V
< CONNECTOR >
CN100 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
CN110 1-815-248-11 CONNECTOR, FPC (ZIF) 27P
CN120 1-770-624-21 PIN, CONNECTOR 7P
< DIODE >
D101 8-719-029-67 DIODE RD5.6UJN-T1
D102 8-719-404-50 DIODE MA111-TX
D121 8-719-404-50 DIODE MA111-TX
D122 8-719-404-50 DIODE MA111-TX
D140 8-719-053-18 DIODE 1SR154-400TE-25
