CDX-5V661/5V661A/5V661D/5V661S
6
4
key flexible boar
(CN903)
3
Put up the mechanism
deck in the direction
of arrow
A
.
4
F2 flexible board
(CN902)
A
4
F1 flexible board
(CN901)
2-4. MECHANISM DECK (MG-160-154)
1
two screws
(PTT2.6
×
6)
1
two screws
(PTT2.6
×
6)
2
Hold the bracket (L), the bracket (R)
and the mechanism deck up
to remove from chassis assy.
5
tension coil spring (float)
7
Remove two oil dampers
from each axis, then
remove the bracket (L).
5
tension coil
spring (float)
5
tension coil
spring (float
5
tension coil
spring (float)
6
tension spring (float 30)
(CDX-5V661A only)
6
tension spring (float 30)
(CDX-5V661A only)
9
sheet (teflon)
9
sheet
(teflon)
9
sheet (teflon)
9
sheet (teflon)
8
Remove two oil dampers
from each axis, then
remove the bracket (R).
0
mechanism deck
(MG-160-154)
oil damper
oil damper
oil damper
oil damper
