Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
71
CDX-5V661/5V661A/5V661D/5V661S
R871 1-216-857-11 METAL CHIP 1M 5% 1/16W
R872 1-216-821-11 METAL CHIP 1K 5% 1/16W
R873 1-216-821-11 METAL CHIP 1K 5% 1/16W
R874 1-216-809-11 METAL CHIP 100 5% 1/16W
R875 1-216-809-11 METAL CHIP 100 5% 1/16W
R876 1-216-821-11 METAL CHIP 1K 5% 1/16W
R877 1-216-821-11 METAL CHIP 1K 5% 1/16W
R878 1-216-841-11 METAL CHIP 47K 5% 1/16W
R879 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R880 1-218-899-11 METAL CHIP 150K 0.5% 1/16W
R881 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
R882 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R883 1-216-845-11 METAL CHIP 100K 5% 1/16W
R884 1-216-849-11 METAL CHIP 220K 5% 1/16W
R885 1-216-837-11 METAL CHIP 22K 5% 1/16W
R886 1-216-841-11 METAL CHIP 47K 5% 1/16W
R889 1-216-845-11 METAL CHIP 100K 5% 1/16W
R890 1-216-841-11 METAL CHIP 47K 5% 1/16W
R891 1-216-841-11 METAL CHIP 47K 5% 1/16W
R892 1-216-847-11 METAL CHIP 150K 5% 1/16W
R893 1-216-809-11 METAL CHIP 100 5% 1/16W
R894 1-216-821-11 METAL CHIP 1K 5% 1/16W
R895 1-216-821-11 METAL CHIP 1K 5% 1/16W
R896 1-216-821-11 METAL CHIP 1K 5% 1/16W
R897 1-216-837-11 METAL CHIP 22K 5% 1/16W
R898 1-216-837-11 METAL CHIP 22K 5% 1/16W
R901 1-216-837-11 METAL CHIP 22K 5% 1/16W
R902 1-216-061-00 RES-CHIP 3.3K 5% 1/10W
R905 1-216-837-11 METAL CHIP 22K 5% 1/16W
R906 1-216-833-11 METAL CHIP 10K 5% 1/16W
R910 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R911 1-216-821-11 METAL CHIP 1K 5% 1/16W
R912 1-216-801-11 METAL CHIP 22 5% 1/16W
R913 1-216-821-11 METAL CHIP 1K 5% 1/16W
R920 1-216-821-11 METAL CHIP 1K 5% 1/16W
R921 1-216-821-11 METAL CHIP 1K 5% 1/16W
R922 1-216-821-11 METAL CHIP 1K 5% 1/16W
R923 1-216-821-11 METAL CHIP 1K 5% 1/16W
R924 1-216-821-11 METAL CHIP 1K 5% 1/16W
R925 1-216-821-11 METAL CHIP 1K 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-809-11 METAL CHIP 100 5% 1/16W
R929 1-216-809-11 METAL CHIP 100 5% 1/16W
R930 1-216-809-11 METAL CHIP 100 5% 1/16W
R931 1-216-821-11 METAL CHIP 1K 5% 1/16W
R932 1-216-821-11 METAL CHIP 1K 5% 1/16W
R933 1-216-821-11 METAL CHIP 1K 5% 1/16W
R934 1-216-821-11 METAL CHIP 1K 5% 1/16W
R935 1-216-821-11 METAL CHIP 1K 5% 1/16W
R936 1-216-821-11 METAL CHIP 1K 5% 1/16W
R937 1-216-821-11 METAL CHIP 1K 5% 1/16W
R940 1-216-821-11 METAL CHIP 1K 5% 1/16W
< THERMISTOR >
TH801 1-804-045-11 THERMISTOR
< VIBRATOR >
X601 1-795-218-21 VIBRATOR, CERAMIC (16.934MHz)
X801 1-795-127-21 VIBRATOR, CERAMIC (12.288MHz)
**************************************************************
A-3326-765-A POS BOARD, COMPLETE
********************
For the parts on the POS board, replace the entire mounted board.
**************************************************************
MISCELLANEOUS
**************
3 1-680-582-11 KEY FLEXIBLE BOARD
104 1-680-581-11 F2 FLEXIBLE BOARD
113 1-757-530-11 CORD (WITH CONNECTOR) (G&H) 12P
(for HEAD UNIT CONNECTING) (5V661D)
115 1-757-532-11 CORD (WITH CONNECTOR) (ISO) 20P
(for HEAD UNIT CONNECTING)
(5V661/5V661A/5V661S)
116 1-757-531-11 CORD (WITH CONNECTOR) (STD)
(for POWER CONNECTING)
(5V661/5V661A/5V661S)
118 1-680-580-11 F1 FLEXIBLE BOARD
505 1-680-583-11 ASSIST FLEXIBLE BOARD
507 1-680-584-11 ADDRESS DETECTION FLEXIBLE BOARD
558 A-3290-640-A MAIN ASSY, BRACKET (DE)
559 1-680-585-11 MECH MOTOR FLEXIBLE BOARD
0 563 A-3315-232-A BLOCK ASSY, OP
M101 A-3315-227-A MOTOR ASSY, SL (SLED)
M103 A-3315-223-A MOTOR ASSY, L (LOADING)
RV1 1-227-318-11 RES, VAR, SLIDE 10K
(ELEVATOR HEIGHT SENSOR)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-792-09 SCREW +PTT 2.6X6 (S)
#2 7-685-790-09 SCREW +PTT 2.6X4 (S)
(5V661/5V661A/5V661S)
#3 7-627-850-37 SCREW, PRECISION +P 1.4X1.4
#4 7-627-553-17 SCREW, PRECISION +P 2X2
#5 7-624-102-04 STOP RING 1.5, TYPE-E
MAIN POS
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
