8
CDX-GT22W/GT120/GT220
3-2. CD MECHANISM BLOCK
Note: Follow the disassembly procedure in the numerical order given.
3-1. SUB PANEL ASSY
2
two claw
s
3
two claws
4
sub panel assy
1
two
screws
(+PTT 2.6
×
6)
4
CNP301
3
1
screw
(+PTT 2.6
×
6)
2
screw
(+PTT 2.6
×
6)
5
two
screws
(+PTT 2.6
×
4)
6
bracket (CD)
7
CD mechanism block
