Sony CDX-GT22W Service Manual

9
CDX-GT22W/GT120/GT220
3-4. SERVO BOARD
3-3. MAIN BOARD
9 MAIN board
insulating sheet
3
2 two screws
(+PTT 2.6
× 8)
1 three ground point screws
(+PTT 2.6
× 6)
7 screw
(+PTT 2.6
× 8)
8 heat sink
4 two screws
(+P 2.6
× 8)
6 screw
(+P 2.6
× 10)
5 two screws
(+PTT 2.6
× 10)
5 SERVO board
SERVO board
claw
claw
3 toothed lock screw
(M 1.7
× 2.5)
2 toothed lock screw
(M 1.7
× 2.5)
1 Remove the eleven solders.
GRY
YEL
BLE
ORG
RED
BLK
RED
WHT
BLK
RED
WHT
4 optical pick-up (16 core
)
(CN1)
