34
CDX-L280
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R561 1-216-806-11 METAL CHIP 56 5% 1/10W
R562 1-216-806-11 METAL CHIP 56 5% 1/10W
R563 1-216-817-11 METAL CHIP 470 5% 1/10W
R564 1-216-817-11 METAL CHIP 470 5% 1/10W
R565 1-216-817-11 METAL CHIP 470 5% 1/10W
R566 1-216-817-11 METAL CHIP 470 5% 1/10W
R567 1-216-817-11 METAL CHIP 470 5% 1/10W
R568 1-216-817-11 METAL CHIP 470 5% 1/10W
R569 1-216-817-11 METAL CHIP 470 5% 1/10W
R570 1-216-817-11 METAL CHIP 470 5% 1/10W
R571 1-216-817-11 METAL CHIP 470 5% 1/10W
R572 1-216-817-11 METAL CHIP 470 5% 1/10W
R573 1-216-817-11 METAL CHIP 470 5% 1/10W
R574 1-216-817-11 METAL CHIP 470 5% 1/10W
R575 1-216-817-11 METAL CHIP 470 5% 1/10W
R576 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S501 1-572-704-31 SWITCH, KEYBOARD (Z)
S502 1-572-704-31 SWITCH, KEYBOARD (SRC (SOURCE))
S503 1-572-704-31 SWITCH, KEYBOARD (MODE)
S504 1-572-704-31 SWITCH, KEYBOARD (SEL)
S505 1-572-704-31 SWITCH, KEYBOARD (+ (Volume))
S506 1-572-704-31 SWITCH, KEYBOARD (– (Volume))
S507 1-572-704-31 SWITCH, KEYBOARD (ATT)
S508 1-572-704-31 SWITCH, KEYBOARD (SENS)
S509 1-572-704-31 SWITCH, KEYBOARD (BTM)
S510 1-572-704-31 SWITCH, KEYBOARD (DSPL)
S511 1-572-704-31 SWITCH, KEYBOARD (OFF)
S512 1-572-704-31 SWITCH, KEYBOARD (D (D-BASS))
S513 1-572-704-31 SWITCH, KEYBOARD (MBP)
S514 1-572-704-31 SWITCH, KEYBOARD (+ > M (SEEK/AMS))
S515 1-572-704-31 SWITCH, KEYBOARD (m . – (SEEK/AMS))
S516 1-572-704-31 SWITCH, KEYBOARD (6)
S517 1-572-704-31 SWITCH, KEYBOARD (5)
S518 1-572-704-31 SWITCH, KEYBOARD (4/SHUF)
S519 1-572-704-31 SWITCH, KEYBOARD (3/REP)
S520 1-572-704-31 SWITCH, KEYBOARD (2)
S521 1-572-704-31 SWITCH, KEYBOARD (1)
*************************************************************
1-683-283-11 IN SELF SW BOARD
****************
< SWITCH >
SW2 1-529-566-31 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-31 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
1-685-337-11 LOAD SW BOARD
***************
< SWITCH >
SW5 1-529-566-31 SWITCH, PUSH (1 KEY) (DOWN)
*************************************************************
A-3274-620-A MAIN BOARD, COMPLETE (including
SPEAKER BOARD)
*********************
* 3-019-565-01 BRACKET (IC)
3-041-261-11 BRACKET (TR)
* 3-224-613-01 HEAT SINK
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-164-346-11 CERAMIC CHIP 1uF 16V
C102 1-164-346-11 CERAMIC CHIP 1uF 16V
C103 1-104-396-11 ELECT 10uF 20% 16V
C104 1-104-396-11 ELECT 10uF 20% 16V
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C110 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C114 1-124-257-00 ELECT 2.2uF 20% 50V
C115 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C116 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C117 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C118 1-164-346-11 CERAMIC CHIP 1uF 16V
C119 1-164-346-11 CERAMIC CHIP 1uF 16V
C201 1-164-346-11 CERAMIC CHIP 1uF 16V
C202 1-164-346-11 CERAMIC CHIP 1uF 16V
C203 1-104-396-11 ELECT 10uF 20% 16V
C204 1-104-396-11 ELECT 10uF 20% 16V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C208 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C213 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C214 1-124-257-00 ELECT 2.2uF 20% 50V
C215 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C216 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C217 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C218 1-164-346-11 CERAMIC CHIP 1uF 16V
C219 1-124-234-00 ELECT 22uF 20% 16V
C401 1-126-163-11 ELECT 4.7uF 20% 50V
C407 1-104-396-11 ELECT 10uF 20% 16V
C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C432 1-124-589-11 ELECT 47uF 20% 16V
C435 1-124-589-11 ELECT 47uF 20% 16V
C603 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C604 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C605 1-104-665-11 ELECT 100uF 20% 10V
C606 1-126-947-11 ELECT 47uF 20% 10V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C610 1-104-396-11 ELECT 10uF 20% 16V
C611 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C612 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C613 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C614 1-164-174-11 CERAMIC CHIP 0.0082uF 10% 25V
C615 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C617 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
DISPLAY
MAINLOAD SWIN SELF SW
