33
CDX-L280
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
DISPLAY
DISPLAY BOARD, COMPLETE
************************
* 3-224-609-03 PLATE (LCD), GROUND
* 3-224-610-02 SHEET (LCD), DIFFUSION
* 3-227-293-01 SHEET (LCD)
* 3-229-751-01 SHEET (LCD.UP)
< CAPACITOR >
C551 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C552 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C553 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C555 1-119-866-11 CERAMIC CHIP 0.68uF 10% 10V
< CONNECTOR >
* CNP551 1-779-131-11 PIN, CONNECTOR 2P
CNP552 1-794-312-21 PIN, CONNECTOR 12P
< DIODE >
D551 8-719-073-15 DIODE SDZ5V1
D552 8-719-988-61 DIODE 1SS355TE-17
D553 8-719-067-70 DIODE SDZ6V2
D554 8-719-068-68 DIODE SDZ6V2WA
D555 8-719-073-15 DIODE SDZ5V1
D561 8-719-053-09 LED SML-310VTT86 (m . – (SEEK/AMS))
D562 8-719-053-09 LED SML-310VTT86 (+ > M (SEEK/AMS))
D563 8-719-053-09 LED SML-310VTT86 (Z)
D564 8-719-053-09 LED SML-310VTT86 (OFF)
D565 8-719-083-98 LED SO1316 (D (D-BASS))
D566 8-719-083-98 LED SO1316 (MBP)
D567 8-719-053-09 LED SML-310VTT86 (5)
D568 8-719-053-09 LED SML-310VTT86 (6)
D569 8-719-053-09 LED SML-310VTT86 (BTM)
D570 8-719-053-09 LED SML-310VTT86 (DSPL)
D571 8-719-053-09 LED SML-310VTT86 (1)
D572 8-719-053-09 LED SML-310VTT86 (2)
D573 8-719-053-09 LED SML-310VTT86 (3/REP)
D574 8-719-053-09 LED SML-310VTT86 (4/SHUF)
D575 8-719-053-09 LED SML-310VTT86 (SEL)
D576 8-719-053-09 LED SML-310VTT86 (MODE)
D577 8-719-053-09 LED SML-310VTT86 (SOURCE)
D578 8-719-053-09 LED SML-310VTT86 (SENS)
D579 8-719-053-09 LED SML-310VTT86 (ATT)
D580 8-719-053-09 LED SML-310VTT86 (– (Volume))
D581 8-719-053-09 LED SML-310VTT86 (+ (Volume))
< IC >
IC551 8-759-369-90 IC LC75822ED
IC552 8-749-017-35 IC KSM-401N
< JUMPER RESISTOR >
JR501 1-216-864-11 METAL CHIP 0 5% 1/10W
JR502 1-216-864-11 METAL CHIP 0 5% 1/10W
JR503 1-216-864-11 METAL CHIP 0 5% 1/10W
< LIQUID CRYSTAL DISPLAY >
LCD501 1-804-300-31 DISPLAY PANEL, LIQUID CRYSTAL
< PILOT LAMP >
PL551 1-518-754-11 LAMP, PILOT
PL552 1-518-754-11 LAMP, PILOT
< RESISTOR >
R501 1-219-286-11 RES-CHIP 680 2% 1/16W
R502 1-219-286-11 RES-CHIP 680 2% 1/16W
R503 1-219-286-11 RES-CHIP 680 2% 1/16W
R504 1-218-847-11 RES-CHIP 1K 2% 1/16W
R505 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R506 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R507 1-218-855-11 RES-CHIP 2.2K 2% 1/16W
R508 1-218-859-11 RES-CHIP 3.3K 2% 1/16W
R509 1-218-863-11 RES-CHIP 4.7K 2% 1/16W
R510 1-218-867-11 RES-CHIP 6.8K 2% 1/16W
R511 1-219-286-11 RES-CHIP 680 2% 1/16W
R512 1-219-286-11 RES-CHIP 680 2% 1/16W
R513 1-219-286-11 RES-CHIP 680 2% 1/16W
R514 1-218-847-11 RES-CHIP 1K 2% 1/16W
R515 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R516 1-218-851-11 RES-CHIP 1.5K 2% 1/16W
R517 1-218-855-11 RES-CHIP 2.2K 2% 1/16W
R518 1-218-859-11 RES-CHIP 3.3K 2% 1/16W
R519 1-218-863-11 RES-CHIP 4.7K 2% 1/16W
R551 1-218-331-11 METAL CHIP 51K 5% 1/10W
R552 1-216-819-11 METAL CHIP 680 5% 1/10W
R553 1-216-857-11 METAL CHIP 1M 5% 1/10W
R554 1-216-807-11 METAL CHIP 68 5% 1/10W
R555 1-216-819-11 METAL CHIP 680 5% 1/10W
R559 1-216-806-11 METAL CHIP 56 5% 1/10W
R560 1-216-806-11 METAL CHIP 56 5% 1/10W
