39
CDX-R3000/RW300
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C303 1-216-864-11 METAL CHIP 0 5% 1/10W
C400 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C406 1-136-154-00 FILM 0.012uF 5% 50V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-104-942-11 ELECT 1uF 20% 50V
C411 1-104-942-11 ELECT 1uF 20% 50V
C414 1-128-428-11 ELECT 10uF 20% 35V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-124-589-11 ELECT 47uF 20% 16V
C424 1-128-428-11 ELECT 10uF 20% 35V
C425 1-128-428-11 ELECT 10uF 20% 35V
C426 1-128-428-11 ELECT 10uF 20% 35V
C428 1-128-428-11 ELECT 10uF 20% 35V
C430 1-126-947-11 ELECT 47uF 20% 16V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C436 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C437 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C438 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C440 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C441 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C444 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C446 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C447 1-124-257-00 ELECT 2.2uF 20% 50V
C450 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C451 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C452 1-128-428-11 ELECT 10uF 20% 35V
C453 1-128-428-11 ELECT 10uF 20% 35V
C600 1-216-864-11 METAL CHIP 0 5% 1/10W
C618 1-126-786-11 ELECT 47uF 20% 16V
C619 1-124-247-61 ELECT 10uF 20% 35V
C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-124-584-00 ELECT 100uF 20% 10V
C704 1-124-584-00 ELECT 100uF 20% 10V
C705 1-124-584-00 ELECT 100uF 20% 10V
C706 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-124-584-00 ELECT 100uF 20% 10V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C802 1-124-589-11 ELECT 47uF 20% 16V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-124-584-00 ELECT 100uF 20% 10V
C810 1-125-701-11 DOUBLE LAYERS 0.047F 5.5V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C813 1-124-584-00 ELECT 100uF 20% 10V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C817 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C818 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C820 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C821 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C823 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C824 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C825 1-124-584-00 ELECT 100uF 20% 10V
C908 1-126-160-11 ELECT 1uF 20% 50V
(US,CND)
C908 1-126-960-11 ELECT 1uF 20% 50V
(E)
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C922 1-131-868-81 ELECT 3300uF 20% 16V
< CONNECTOR >
CN751 1-817-536-11 CONNECTOR, BOARD TO BOARD 28P
CNP800 1-794-311-21 PLUG, CONNECTOR 12P
CNP900 1-764-270-21 JACK (REMOTE IN) (E)
CNP901 1-774-701-21 PIN, CONNECTOR 16P
< DIODE >
D400 8-719-988-61 DIODE 1SS355TE-17
D600 8-719-069-55 DIODE UDZS-TE17-5.6B
D702 1-216-864-11 METAL CHIP 0 5% 1/10W
D801 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-977-12 DIODE DTZ6.8B
D810 8-719-988-61 DIODE 1SS355TE-17 (E)
D811 8-719-109-97 DIODE RD6.8ES-B2
D812 8-719-109-97 DIODE RD6.8ES-B2
D813 8-719-109-97 DIODE RD6.8ES-B2
D814 8-719-109-97 DIODE RD6.8ES-B2
D815 8-719-109-97 DIODE RD6.8ES-B2
D816 8-719-109-97 DIODE RD6.8ES-B2
D817 8-719-109-97 DIODE RD6.8ES-B2
D820 8-719-991-33 DIODE 1SS133T-77
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
D906 8-719-200-82 DIODE 11ES2
D907 8-719-200-82 DIODE 11ES2
D908 8-719-200-82 DIODE 11ES2
D909 8-719-200-82 DIODE 11ES2
D912 8-719-083-66 DIODE UDZSTE-1718B
D914 8-719-977-12 DIODE DTZ6.8B
D915 8-719-056-84 DIODE UDZSTE-177.5B
D916 8-719-200-82 DIODE 11ES2
D917 8-719-200-82 DIODE 11ES2
D919 8-719-049-38 DIODE 1N5404TU
D921 8-719-200-82 DIODE 11ES2
D922 8-719-200-82 DIODE 11ES2
< IC >
IC100 6-705-360-01 IC TDA8588BJ/N2
IC401 6-705-372-01 IC BD3808FS-FE2
IC801 6-803-820-01 IC MB90473PF-G166-BNDE1
IC802 8-759-659-13 IC PST3428UL
< JUMPER RESISTOR >
JR5 1-216-864-11 METAL CHIP 0 5% 1/10W
JR6 1-216-864-11 METAL CHIP 0 5% 1/10W
JR10 1-216-864-11 METAL CHIP 0 5% 1/10W
JR11 1-216-864-11 METAL CHIP 0 5% 1/10W
JR103 1-216-864-11 METAL CHIP 0 5% 1/10W
