Sony CDX-R3000 Service Manual

40
CDX-R3000/RW300
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COIL >
L400 1-414-398-11 INDUCTOR 10uH
L602 1-414-394-41 INDUCTOR 2.2uH
L700 1-410-501-11 INDUCTOR 2.2uH
L701 1-410-501-11 INDUCTOR 2.2uH
L702 1-410-509-11 INDUCTOR 10uH
L900 1-456-617-11 COIL, CHOKE 250uH
< JACK >
PJ401 1-774-698-11 JACK, PIN 2P (AUDIO OUT REAR)
PJ601 1-793-598-11 JACK (ANTENNA)
< TRANSISTOR >
Q400 8-729-038-71 TRANSISTOR KRC107S
Q401 8-729-038-55 TRANSISTOR KRA103S
Q402 6-550-752-01 TRANSISTOR DTC614TKT146
Q403 6-550-752-01 TRANSISTOR DTC614TKT146
Q404 6-550-752-01 TRANSISTOR DTC614TKT146
Q405 6-550-752-01 TRANSISTOR DTC614TKT146
Q406 6-550-752-01 TRANSISTOR DTC614TKT146
Q407 6-550-752-01 TRANSISTOR DTC614TKT146
Q601 8-729-920-85 TRANSISTOR 2SD1664-QR
Q800 8-729-038-55 TRANSISTOR KRA103S
Q900 8-729-034-51 TRANSISTOR KTC3875
Q902 8-729-038-67 TRANSISTOR KRC102S
Q906 8-729-034-51 TRANSISTOR KTC3875
Q907 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-839-11 METAL CHIP 33K 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R414 1-216-809-11 METAL CHIP 100 5% 1/10W
R415 1-216-809-11 METAL CHIP 100 5% 1/10W
R416 1-216-809-11 METAL CHIP 100 5% 1/10W
R417 1-216-809-11 METAL CHIP 100 5% 1/10W
R418 1-216-841-11 METAL CHIP 47K 5% 1/10W
R419 1-216-841-11 METAL CHIP 47K 5% 1/10W
R420 1-216-841-11 METAL CHIP 47K 5% 1/10W
R421 1-216-841-11 METAL CHIP 47K 5% 1/10W
R424 1-216-805-11 METAL CHIP 47 5% 1/10W
R427 1-216-809-11 METAL CHIP 100 5% 1/10W
R429 1-247-807-31 CARBON 100 5% 1/4W
R431 1-247-807-31 CARBON 100 5% 1/4W
R432 1-216-809-11 METAL CHIP 100 5% 1/10W
R435 1-216-809-11 METAL CHIP 100 5% 1/10W
R436 1-216-809-11 METAL CHIP 100 5% 1/10W
R437 1-216-821-11 METAL CHIP 1K 5% 1/10W
R440 1-216-809-11 METAL CHIP 100 5% 1/10W
R441 1-216-809-11 METAL CHIP 100 5% 1/10W
R442 1-216-841-11 METAL CHIP 47K 5% 1/10W
R443 1-216-841-11 METAL CHIP 47K 5% 1/10W
R447 1-216-809-11 METAL CHIP 100 5% 1/10W
R448 1-216-841-11 METAL CHIP 47K 5% 1/10W
R603 1-247-807-31 CARBON 100 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R606 1-216-809-11 METAL CHIP 100 5% 1/10W
R607 1-216-809-11 METAL CHIP 100 5% 1/10W
R608 1-216-809-11 METAL CHIP 100 5% 1/10W
R615 1-216-821-11 METAL CHIP 1K 5% 1/10W
R703 1-216-864-11 METAL CHIP 0 5% 1/10W
R705 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-809-11 METAL CHIP 100 5% 1/10W
R709 1-216-864-11 METAL CHIP 0 5% 1/10W
R722 1-216-809-11 METAL CHIP 100 5% 1/10W
R800 1-216-841-11 METAL CHIP 47K 5% 1/10W
(E)
R801 1-216-809-11 METAL CHIP 100 5% 1/10W
R802 1-216-864-11 METAL CHIP 0 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R806 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R808 1-216-845-11 METAL CHIP 100K 5% 1/10W
(E)
R808 1-216-864-11 METAL CHIP 0 5% 1/10W
(US,CND)
R809 1-216-845-11 METAL CHIP 100K 5% 1/10W
(E)
R810 1-216-845-11 METAL CHIP 100K 5% 1/10W
R811 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-216-845-11 METAL CHIP 100K 5% 1/10W
R815 1-249-435-11 CARBON 33K 5% 1/4W
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-809-11 METAL CHIP 100 5% 1/10W
R821 1-216-817-11 METAL CHIP 470 5% 1/10W
R822 1-216-817-11 METAL CHIP 470 5% 1/10W
R823 1-216-817-11 METAL CHIP 470 5% 1/10W
R824 1-216-849-11 METAL CHIP 220K 5% 1/10W
R825 1-216-849-11 METAL CHIP 220K 5% 1/10W
R826 1-216-843-11 METAL CHIP 68K 5% 1/10W
R828 1-216-809-11 METAL CHIP 100 5% 1/10W
R830 1-216-809-11 METAL CHIP 100 5% 1/10W
R832 1-216-867-11 METAL CHIP 6.8K 5% 1/10W
R833 1-249-417-11 CARBON 1K 5% 1/4W
R834 1-216-867-11 METAL CHIP 6.8K 5% 1/10W
R835 1-216-845-11 METAL CHIP 100K 5% 1/10W
R837 1-216-864-11 METAL CHIP 0 5% 1/10W
R838 1-216-845-11 METAL CHIP 100K 5% 1/10W
R839 1-216-809-11 METAL CHIP 100 5% 1/10W
R840 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R843 1-216-809-11 METAL CHIP 100 5% 1/10W
R844 1-216-845-11 METAL CHIP 100K 5% 1/10W
R846 1-216-845-11 METAL CHIP 100K 5% 1/10W
R847 1-216-845-11 METAL CHIP 100K 5% 1/10W
R848 1-216-845-11 METAL CHIP 100K 5% 1/10W
R849 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R851 1-216-809-11 METAL CHIP 100 5% 1/10W
R852 1-216-864-11 METAL CHIP 0 5% 1/10W
R853 1-216-864-11 METAL CHIP 0 5% 1/10W
MAIN
