41
CDX-R3000/RW300
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R854 1-216-864-11 METAL CHIP 0 5% 1/10W
R860 1-216-845-11 METAL CHIP 100K 5% 1/10W
R861 1-216-809-11 METAL CHIP 100 5% 1/10W
(E)
R862 1-216-809-11 METAL CHIP 100 5% 1/10W
(E)
R864 1-249-441-11 CARBON 100K 5% 1/4W
R865 1-249-441-11 CARBON 100K 5% 1/4W
R873 1-216-845-11 METAL CHIP 100K 5% 1/10W
R901 1-216-845-11 METAL CHIP 100K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R903 1-216-841-11 METAL CHIP 47K 5% 1/10W
R904 1-216-841-11 METAL CHIP 47K 5% 1/10W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-469-144-21 FERRITE, EMI (SMD) (E)
R915 1-469-144-21 FERRITE, EMI (SMD) (E)
R917 1-249-421-11 CARBON 2.2K 5% 1/4W
R925 1-216-845-11 METAL CHIP 100K 5% 1/10W
R927 1-216-833-11 METAL CHIP 10K 5% 1/10W
R928 1-249-421-11 CARBON 2.2K 5% 1/4W
R931 1-216-073-00 RES-CHIP 10K 5% 1/10W
R932 1-216-073-00 RES-CHIP 10K 5% 1/10W
R936 1-216-864-11 METAL CHIP 0 5% 1/10W
< SWITCH >
S800 1-571-478-11 SWITCH, SLIDE (FREQUENCY SELECT) (E)
S802 1-762-638-21 SWITCH, TACTILE (RESET)
< TUNER >
TUX601 A-3220-959-A TUNER UNIT (TUX-032)
< VIBRATOR >
X800 1-767-993-21 VIBRATOR, CRYSTAL (3.68MHz)
X801 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
SENSOR BOARD
**************
< SWITCH >
SW2 1-529-566-61 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-61 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
A-3283-350-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C1 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C6 1-100-381-11 ELECT CHIP 10uF 20% 16V
C7 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C11 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C13 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C18 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C25 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C28 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C29 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C30 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C31 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C32 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C34 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C37 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C38 1-104-609-11 ELECT CHIP 100uF 20% 4V
C39 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C70 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C71 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C72 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C73 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C74 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C75 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C76 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C77 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C78 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C79 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CN1 1-817-275-21 CONNECTOR, BOARD TO BOARD 28P
CN2 1-794-153-21 CONNECTOR, FPC (ZIF) 16P
< FERRITE BEAD >
FB1 1-414-760-21 FERRITE, EMI (SMD)
< IC >
IC1 6-703-699-01 IC uPD63712GC-8EU-A
IC2 6-705-002-01 IC BA5966FP-FE2
< FERRITE BEAD >
JR40 1-414-760-21 FERRITE, EMI (SMD)
JR41 1-414-760-21 FERRITE, EMI (SMD)
JR90 1-414-760-21 FERRITE, EMI (SMD)
JR91 1-414-760-21 FERRITE, EMI (SMD)
< TRANSISTOR >
Q1 8-729-904-87 TRANSISTOR 2SB1197K-R
< RESISTOR >
R1 1-216-841-11 METAL CHIP 47K 5% 1/10W
R6 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7 1-216-840-11 METAL CHIP 39K 5% 1/10W
R9 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R11 1-216-833-11 METAL CHIP 10K 5% 1/10W
R12 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN SENSOR SERVO
To Next Page
