Sony CDX-R3000 Service Manual

5
CDX-R3000/RW300
3. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY BOARD
**************
1-780-120-11 CONDUCTIVE BOARD, CONNECTION
3-258-884-01 SHEET (ILLUMINATOR)
< CAPACITOR >
C551 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C552 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C553 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C958 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C960 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-794-312-21 PIN, CONNECTOR 12P
< DIODE >
D502 8-719-977-12 DIODE DTZ6.8B
D503 8-719-977-12 DIODE DTZ6.8B
D504 8-719-977-12 DIODE DTZ6.8B
D551 8-719-080-28 DIODE KDZ5.1V
D552 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC501 6-705-180-01 IC LC75827W
IC502 6-600-384-01 IC KSM-401E (IR)
IC906 6-705-374-01 IC MM3033DULE
< LIQUID CRYSTAL DISPLAY >
LCD501 1-805-450-11 DISPLAY PANEL, LIQUID CRYSTAL
< LED >
LED501 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED502 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED503 6-500-510-01 LED CL-195PG-CD-T (DISC IND) (RW300)
LED503 8-719-053-09 LED SML-310VTT86 (DISC IND) (R3000)
LED504 6-500-510-01 LED CL-195PG-CD-T (2) (RW300)
LED504 8-719-053-09 LED SML-310VTT86 (2) (R3000)
LED505 6-500-510-01 LED CL-195PG-CD-T (1) (RW300)
LED505 8-719-053-09 LED SML-310VTT86 (1) (R3000)
LED506 6-500-510-01 LED CL-195PG-CD-T (SENS) (RW300)
LED506 8-719-053-09 LED SML-310VTT86 (SENS) (R3000)
LED507 6-500-510-01 LED CL-195PG-CD-T (ATT) (RW300)
LED507 8-719-053-09 LED SML-310VTT86 (ATT) (R3000)
LED508 6-500-510-01 LED CL-195PG-CD-T (8) (RW300)
LED508 8-719-053-09 LED SML-310VTT86 (8) (R3000)
LED509 6-500-510-01 LED CL-195PG-CD-T (5) (RW300)
LED509 8-719-053-09 LED SML-310VTT86 (5) (R3000)
LED510 6-500-510-01 LED CL-195PG-CD-T (4) (RW300)
LED510 8-719-053-09 LED SML-310VTT86 (4) (R3000)
LED511 6-500-510-01 LED CL-195PG-CD-T (3) (RW300)
LED511 8-719-053-09 LED SML-310VTT86 (3) (R3000)
LED512 6-500-510-01 LED CL-195PG-CD-T (SHUF) (RW300)
LED512 8-719-053-09 LED SML-310VTT86 (SHUF) (R3000)
LED513 6-500-510-01 LED CL-195PG-CD-T (DSPL) (RW300)
LED513 8-719-053-09 LED SML-310VTT86 (DSPL) (R3000)
LED514 6-500-510-01 LED CL-195PG-CD-T (EQ3) (RW300)
LED514 8-719-053-09 LED SML-310VTT86 (EQ3) (R3000)
LED515 6-500-510-01 LED CL-195PG-CD-T (OFF) (RW300)
LED515 8-719-053-09 LED SML-310VTT86 (OFF) (R3000)
LED516 6-500-510-01 LED CL-195PG-CD-T (SEEK – m .)
(RW300)
LED516 8-719-053-09 LED SML-310VTT86 (SEEK – m .)
(R3000)
LED517 6-500-510-01 LED CL-195PG-CD-T (SEEK + > M)
(RW300)
LED517 8-719-053-09 LED SML-310VTT86 (SEEK + > M)
(R3000)
LED518 6-500-510-01 LED CL-195PG-CD-T (REP) (RW300)
LED518 8-719-053-09 LED SML-310VTT86 (REP) (R3000)
LED520 6-500-510-01 LED CL-195PG-CD-T (VOLUME –) (RW300)
LED520 8-719-053-09 LED SML-310VTT86 (VOLUME –) (R3000)
LED521 6-500-510-01 LED CL-195PG-CD-T (VOLUME +) (RW300)
LED521 8-719-053-09 LED SML-310VTT86 (VOLUME +) (R3000)
LED522 6-500-510-01 LED CL-195PG-CD-T (SEL) (RW300)
LED522 8-719-053-09 LED SML-310VTT86 (SEL) (R3000)
LED524 6-500-510-01 LED CL-195PG-CD-T (SOURCE) (RW300)
LED524 8-719-053-09 LED SML-310VTT86 (SOURCE) (R3000)
LED525 6-500-510-01 LED CL-195PG-CD-T (MODE) (RW300)
LED525 8-719-053-09 LED SML-310VTT86 (MODE) (R3000)
< TRANSISTOR >
Q502 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R501 1-216-819-11 METAL CHIP 680 5% 1/10W
R502 1-216-819-11 METAL CHIP 680 5% 1/10W
R503 1-216-819-11 METAL CHIP 680 5% 1/10W
R504 1-216-821-11 METAL CHIP 1K 5% 1/10W
R505 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
•Abbreviation
CND : Canadian model
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISPLAY
