Sony CDX-R3000 Service Manual

6
CDX-R3000/RW300
Ref. No. Part No. Description Remark
R506 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R507 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R508 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R509 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R510 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R511 1-216-819-11 METAL CHIP 680 5% 1/10W
R512 1-216-819-11 METAL CHIP 680 5% 1/10W
R513 1-216-819-11 METAL CHIP 680 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R516 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R517 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R518 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R519 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R531 1-216-813-11 METAL CHIP 220 5% 1/10W
R532 1-216-813-11 METAL CHIP 220 5% 1/10W
R533 1-216-813-11 METAL CHIP 220 5% 1/10W
R535 1-216-815-11 METAL CHIP 330 5% 1/10W
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
R537 1-216-809-11 METAL CHIP 100 5% 1/10W
R551 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R552 1-216-815-11 METAL CHIP 330 5% 1/10W
R553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R554 1-216-821-11 METAL CHIP 1K 5% 1/10W
R555 1-216-821-11 METAL CHIP 1K 5% 1/10W
R556 1-216-840-11 METAL CHIP 39K 5% 1/10W
R557 1-216-821-11 METAL CHIP 1K 5% 1/10W
R558 1-216-821-11 METAL CHIP 1K 5% 1/10W
R559 1-216-821-11 METAL CHIP 1K 5% 1/10W
R560 1-216-821-11 METAL CHIP 1K 5% 1/10W
R561 1-216-857-11 METAL CHIP 1M 5% 1/10W
R571 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R571 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R572 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R572 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R573 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R573 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R574 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R574 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R575 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R575 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R576 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R576 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R577 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R577 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
DISPLAY
R578 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R578 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R579 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R579 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
R580 1-216-805-11 METAL CHIP 47 5% 1/10W
(RW300)
R580 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3000)
< SWITCH >
S501 1-786-763-11 SWITCH, TACTILE (OPEN/EJECT)
S502 1-786-763-11 SWITCH, TACTILE (OPEN/EJECT)
S503 1-786-763-11 SWITCH, TACTILE (OFF)
S504 1-786-763-11 SWITCH, TACTILE (SOURCE)
S505 1-786-763-11 SWITCH, TACTILE (MODE)
S506 1-786-763-11 SWITCH, TACTILE (SEL)
S507 1-786-763-11 SWITCH, TACTILE (VOLUME +)
S508 1-786-763-11 SWITCH, TACTILE (VOLUME –)
S509 1-786-763-11 SWITCH, TACTILE (ATT)
S510 1-786-763-11 SWITCH, TACTILE (BTM/SENS)
S511 1-786-763-11 SWITCH, TACTILE (1)
S512 1-786-763-11 SWITCH, TACTILE (2)
S513 1-786-763-11 SWITCH, TACTILE (SEEK + > M)
S514 1-786-763-11 SWITCH, TACTILE (SEEK – m .)
S515 1-786-763-11 SWITCH, TACTILE (EQ3)
S516 1-786-763-11 SWITCH, TACTILE (DSPL)
S517 1-786-763-11 SWITCH, TACTILE (SHUF)
S518 1-786-763-11 SWITCH, TACTILE (6)
S519 1-786-763-11 SWITCH, TACTILE (5)
S520 1-786-763-11 SWITCH, TACTILE (4)
S521 1-786-763-11 SWITCH, TACTILE (3)
S522 1-529-566-61 SWITCH, PUSH (1 KEY) (SHUTTER)
S523 1-786-763-11 SWITCH, TACTILE (REP)
Ref. No. Part No. Description Remark
