Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51
CFD-E75
R860 1-216-841-11 METAL CHIP 47K 5% 1/16W
R861 1-216-841-11 METAL CHIP 47K 5% 1/16W
R865 1-216-837-11 METAL CHIP 22K 5% 1/16W
R866 1-216-821-11 METAL CHIP 1K 5% 1/16W
R867 1-216-821-11 METAL CHIP 1K 5% 1/16W
R868 1-216-821-11 METAL CHIP 1K 5% 1/16W
R869 1-216-821-11 METAL CHIP 1K 5% 1/16W
R870 1-216-821-11 METAL CHIP 1K 5% 1/16W
R871 1-216-821-11 METAL CHIP 1K 5% 1/16W
R873 1-216-815-11 METAL CHIP 330 5% 1/16W
R876 1-216-821-11 METAL CHIP 1K 5% 1/16W
R877 1-216-821-11 METAL CHIP 1K 5% 1/16W
R878 1-216-821-11 METAL CHIP 1K 5% 1/16W
R879 1-216-845-11 METAL CHIP 100K 5% 1/16W
R880 1-216-821-11 METAL CHIP 1K 5% 1/16W
R881 1-216-833-11 METAL CHIP 10K 5% 1/16W
R882 1-216-821-11 METAL CHIP 1K 5% 1/16W
R883 1-216-821-11 METAL CHIP 1K 5% 1/16W
R884 1-216-841-11 METAL CHIP 47K 5% 1/16W
R886 1-216-853-11 METAL CHIP 470K 5% 1/16W
R888 1-216-851-11 METAL CHIP 330K 5% 1/16W
R890 1-216-851-11 METAL CHIP 330K 5% 1/16W
R891 1-216-833-11 METAL CHIP 10K 5% 1/16W
R892 1-216-833-11 METAL CHIP 10K 5% 1/16W
R893 1-216-845-11 METAL CHIP 100K 5% 1/16W
R894 1-216-845-11 METAL CHIP 100K 5% 1/16W
R895 1-216-841-11 METAL CHIP 47K 5% 1/16W
R896 1-216-841-11 METAL CHIP 47K 5% 1/16W
R899 1-216-851-11 METAL CHIP 330K 5% 1/16W
< VIBRATOR >
X801 1-767-184-11 VIBRATOR, CERAMIC (4.19MHz)
X802 1-767-697-11 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
* 1-681-859-13 OPR/BATT LED BOARD
*******************
< LED >
D401 8-719-085-67 LED L-34SRDLK (OPR/BATT)
< RESISTOR >
R421 1-216-813-11 METAL CHIP 220 5% 1/16W
**************************************************************
* A-3062-357-A POWER BOARD, COMPLETE
(US, CND, E92, TW, MX)
* A-3062-740-A POWER BOARD, COMPLETE (SP, KR, AR)
***********************
1-533-233-31 HOLDER, FUSE
3-232-530-01 PLATE SHIELD (TRANS)
3-232-531-01 ADHESIVE SHEET (TRANS)
7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C190 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C191 1-126-947-11 ELECT 47uF 20% 10V
C192 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C193 1-126-934-11 ELECT 220uF 20% 10V
C194 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C195 1-126-927-11 ELECT 2200uF 20% 10V
C196 1-126-960-11 ELECT 1uF 20% 50V
C197 1-126-959-11 ELECT 0.47uF 20% 50V
C290 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C291 1-126-947-11 ELECT 47uF 20% 10V
C292 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C293 1-126-934-11 ELECT 220uF 20% 10V
C294 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C295 1-126-927-11 ELECT 2200uF 20% 10V
C296 1-126-960-11 ELECT 1uF 20% 50V
C297 1-126-959-11 ELECT 0.47uF 20% 50V
C391 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C392 1-126-934-11 ELECT 220uF 20% 10V
C393 1-104-665-11 ELECT 100uF 20% 10V
C394 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C395 1-126-934-11 ELECT 220uF 20% 10V
C397 1-126-934-11 ELECT 220uF 20% 10V
C398 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C399 1-128-551-11 ELECT 22uF 20% 25V
C901 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
(SP, KR, AR)
C901 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, E92, TW, MX)
C902 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
(SP, KR, AR)
C902 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, E92, TW, MX)
C903 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
(SP, KR, AR)
C903 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, E92, TW, MX)
C904 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
(SP, KR, AR)
C904 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, E92, TW, MX)
C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C910 1-126-937-11 ELECT 4700uF 20% 16V
C911 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNP392 1-564-778-11 PLUG, CONNECTOR (2.5mm) 4P
* CNP901 1-785-655-21 PIN, CONNECTOR (PC BOARD) 3P
CNP902 1-569-596-11 PLUG, CONNECTOR (2.5mm) 3P
< DIODE >
D390 8-719-988-61 DIODE 1SS355TE-17
D391 8-719-988-61 DIODE 1SS355TE-17
D392 8-719-056-83 DIODE UDZ-TE-17-6.8B
D393 8-719-109-97 DIODE MTZJ-6.8B
D394 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-046-07 DIODE 2A02M
D902 8-719-046-07 DIODE 2A02M
D903 8-719-046-07 DIODE 2A02M
D904 8-719-046-07 DIODE 2A02M
D905 8-719-988-61 DIODE 1SS355TE-17
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN OPR/BATT LED POWER
Ver 1.1
