Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
52
CFD-E75
D906 8-719-988-61 DIODE 1SS355TE-17
D907 8-719-988-61 DIODE 1SS355TE-17
D908 8-719-056-73 DIODE UDZ-TE-17-2.7B
D909 8-719-988-61 DIODE 1SS355TE-17
D910 8-719-050-84 DIODE RB441Q-40T-77
< FUSE >
0 F901 1-533-469-11 FUSE, GLASS TUBE (DIA.5) (2.5A/250V)
(SP, KR, AR)
0 F901 1-576-105-11 FUSE (2.5A/250V) (US, CND, E92, TW, MX)
< IC >
IC390 8-759-426-51 IC BA5417
< JACK >
J301 1-566-891-11 JACK (i)
< COIL >
L190 1-414-142-61 INDUCTOR 1uH
L290 1-414-142-61 INDUCTOR 1uH
L391 1-414-142-61 INDUCTOR 1uH
< TRANSISTOR >
Q191 8-729-036-89 TRANSISTOR KTC3198GR-A
Q291 8-729-036-89 TRANSISTOR KTC3198GR-A
Q390 8-729-052-52 TRANSISTOR KTC2026Y
Q391 8-729-052-52 TRANSISTOR KTC2026Y
Q392 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q393 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R193 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R194 1-216-809-11 METAL CHIP 100 5% 1/16W
R196 1-216-817-11 METAL CHIP 470 5% 1/16W
R197 1-216-835-11 METAL CHIP 15K 5% 1/16W
R198 1-216-821-11 METAL CHIP 1K 5% 1/16W
R290 1-216-813-11 METAL CHIP 220 5% 1/16W
R291 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R293 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R294 1-216-809-11 METAL CHIP 100 5% 1/16W
R296 1-216-817-11 METAL CHIP 470 5% 1/16W
R297 1-216-835-11 METAL CHIP 15K 5% 1/16W
R298 1-216-821-11 METAL CHIP 1K 5% 1/16W
R390 1-216-805-11 METAL CHIP 47 5% 1/16W
R391 1-216-809-11 METAL CHIP 100 5% 1/16W
R392 1-216-811-11 METAL CHIP 150 5% 1/16W
R393 1-216-797-11 METAL CHIP 10 5% 1/16W
R394 1-249-407-11 CARBON 150 5% 1/4W
R395 1-216-821-11 METAL CHIP 1K 5% 1/16W
R396 1-216-841-11 METAL CHIP 47K 5% 1/16W
R397 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R398 1-216-853-11 METAL CHIP 470K 5% 1/16W
R901 1-216-809-11 METAL CHIP 100 5% 1/16W
R902 1-216-809-11 METAL CHIP 100 5% 1/16W
0 R903 1-219-149-11 FUSIBLE 1 5% 1/4W F
< TRANSFORMER >
0 T901 1-437-319-11 TRANSFORMER, POWER
(US, CND, E92, TW, MX)
0 T901 1-437-320-11 TRANSFORMER, POWER (SP, KR, AR)
**************************************************************
* A-3347-189-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-126-947-11 ELECT 47uF 20% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C107 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-126-947-11 ELECT 47uF 20% 10V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C204 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C205 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20% 50V
C207 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-126-947-11 ELECT 47uF 20% 10V
C305 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN303 1-784-774-11 CONNECTOR, FFC 13P
< IC >
IC301 8-759-264-71 IC TA2068N
< RESISTOR >
JC301 1-216-864-11 METAL CHIP 0 5% 1/16W
JC302 1-216-864-11 METAL CHIP 0 5% 1/16W
JC303 1-216-864-11 METAL CHIP 0 5% 1/16W
JC304 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-807-11 METAL CHIP 68 5% 1/16W
R103 1-216-843-11 METAL CHIP 68K 5% 1/16W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R105 1-216-835-11 METAL CHIP 15K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R110 1-216-809-11 METAL CHIP 100 5% 1/16W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
POWER TC
Ver 1.1
