16
Changing the tuning interval
When using the CD player abroad, change the AM tuning interval, if necessary. Set the STEP
switch (inside the lid) to “9 kHz” or “10 kHz” using a pointed material.
9 kHz area: Asia and Europe
10 kHz area: the U.S.A., Canada and South America
Notes
• The interval will not change until you once turn off the radio and then turn it on again.
• After changing the tuning interval, you need to preset radio stations again.

Sony D-FS601 Operating Instructions (primary manual) Specifications

Radio Frequencies

FM frequency range	87.5-108MHz
AM frequency range	530-1710kHz
TV frequency range	Ch. 2-13, 1 ch. Step

Power

input voltage	DC-In 4.5V
power requirements	DC 4.5V “AA” x 2 batteries
battery life	50 hours with “AA” Sony alkaline batteries x 2

Weight and Dimensions

dimensions	5 1/4" x 1 1/2" x 5 3/4" (134 x 38.1 x 147.5mm)
weight	12 5/8 oz (360g) w/out batteries
