Sony DCR-PC1000 - Electrical Parts List

5-15
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-PC1000/PC1000E
CD-569
A-1099-841-A CD-569 BOARD, COMPLETE
**********************
(IC2001,IC2002 and IC2003 are not included in this COMPLETE board.)
(IC2001,IC2002 and IC2003 are included in PRISM ASSY(A-1110-134-A).)
< CAPACITOR >
C2001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2003 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2004 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2005 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2007 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2009 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2010 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2014 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2016 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2017 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2018 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2020 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2021 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2022 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2023 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2024 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2025 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2026 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2027 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2028 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2029 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2030 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2033 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2034 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2035 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2036 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2037 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2038 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2039 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C2040 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C2041 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2042 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2043 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2044 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2046 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2047 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2048 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2049 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2050 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2051 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2052 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2053 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2054 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2055 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2056 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2057 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2058 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2059 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C2060 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2061 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2062 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2063 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2064 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C2065 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2066 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2067 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2068 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2069 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN1001 1-816-870-11 CONNECTOR, BOARD TO BOARD 60P
< IC >
IC2001 not supplied IMX009ALZ-13 (CMOS IMAGER)
IC2002 not supplied IMX009ALZ-13 (CMOS IMAGER)
IC2003 not supplied IMX009ALZ-13 (CMOS IMAGER)
(IC2001,IC2002 and IC2003 are not included
in this COMPLETE of CD-569 board.)
(IC2001,IC2002 and IC2003 are included
in PRISM ASSY(A-1110-134-A).)
< RESISTOR >
R2001 1-216-864-11 SHORT CHIP 0
R2002 1-216-864-11 SHORT CHIP 0
R2003 1-216-864-11 SHORT CHIP 0
R2004 1-216-864-11 SHORT CHIP 0
R2005 1-216-864-11 SHORT CHIP 0
R2006 1-216-864-11 SHORT CHIP 0
R2007 1-218-990-11 SHORT CHIP 0
R2008 1-218-990-11 SHORT CHIP 0
R2009 1-216-864-11 SHORT CHIP 0
R2010 1-216-864-11 SHORT CHIP 0
R2011 1-218-990-11 SHORT CHIP 0
R2012 1-218-990-11 SHORT CHIP 0
R2013 1-218-990-11 SHORT CHIP 0
R2014 1-218-990-11 SHORT CHIP 0
R2015 1-216-864-11 SHORT CHIP 0
R2016 1-216-864-11 SHORT CHIP 0
R2017 1-216-864-11 SHORT CHIP 0
R2018 1-218-990-11 SHORT CHIP 0
R2019 1-216-864-11 SHORT CHIP 0
R2020 1-218-990-11 SHORT CHIP 0
R2021 1-218-990-11 SHORT CHIP 0
************************************************************
Be sure to read “Precautions upon replacing CMOS imager”
on page 4-3 when changing the CMOS imager.
