— 2 —
DCR-PC1000/PC1000E
AC Adaptor (1)
0
1-479-047-11
Power cord (Main lead) (1)
(US, CND model)
0
1-790-107-41
Power cord (Main lead) (1)
(AEP, NE, E model)
0
1-769-608-31
Power cord (Main lead) (1)
(UK, HK model)
0
1-783-374-12
Power cord (Main lead) (1)
(KR model)
0
1-823-947-12
Power cord (Main lead) (1)
(AUS model)
0
1-827-945-12
Power cord (Main lead) (1)
(JE model)
0
1-790-732-71
Page
5. REPAIR PARTS LIST
5-1. EXPLODED VIEWS
: Changed portion : Deleted portion
Before change After change
5-6
5-1-4. LCD SECTION
LED901 1-478-929-21 BLOCK, LIGHT GUIDE PLATE (2.7)
LED901 1-478-929-11 BLOCK, LIGHT GUIDE PLATE (2.7)
5-7
5-1-5. (G) FRAME SECTION
X X X
217 2-596-985-01 METER (4 (HOLE METER 1.8))
5-13
Checking supplied accessories.
AC Adaptor (1)
0
1-479-285-21
Power cord (Main lead) (1)
(US, CND model)
0
1-790-107-42
Power cord (Main lead) (1)
(AEP, NE, E model)
0
1-575-131-82
Power cord (Main lead) (1)
(UK, HK model)
0
1-783-374-11
Power cord (Main lead) (1)
(KR model)
0
1-776-985-12
Power cord (Main lead) (1)
(AUS model)
0
1-827-945-11
Power cord (Main lead) (1)
(JE model)
0
1-792-549-12
Ref. No. Part No. DescriptionRef. No. Part No. Description
B
ns
208
222
217
209
207
(SIZE : 9mm
×
28mm)
B
ns
208
222
209
207
(SIZE : 9mm
×
28mm)
4-90
FP-168 BOARD
11
1-865-889-
Page Before change After change
: Added portion
4-3. PRINTED WIRING BOARDS
To Next Page
