Sony DCR-PC103E - Page 37

DCR-PC103E/PC104E/PC105/PC105E
HELP
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
16/Apr/2003
CABINET (R) SECTION
Radiation sheet (R)
Battery bracket
Harness
(PB-052)
Fixed DC connector plate
Fixed DC connector plate
BJ-004 board
BJ-004 board
BJ-004 board
Shade cushion
LED
(BJ-004 board)
FP-697 board
LCD hinge assembly
Harness (PB-052)
Blind plate assembly
Harness protection
sheet
Harness fixed
sheet
Cushion (CF)
Switch
block
BJ-004 board
Muffle sheet
(small)
Harness
Fixed DC
connector plate
BJ-004
board
