DCR-PC103E/PC104E/PC105/PC105E
HELP
VTR OVERALL SECTION
LENS/EVF/ST SECTION
Lens fixed sheet
Connector retainer
cushion
Connector retainer
cushion
Lens sheet (ST)
VF-156 board
CD-444 board
Flexible board
(from the Lens device)
EVF section
Lens section
CD shield sheet
Flexible board
(From the flash unit (FL4400))
(PC105/PC105E)
Adhesive portion
FP-672 board
