DCR-PC103E/PC104E/PC105/PC105E
HELP
MS cushion
Radiation sheet (VC)
VC spacer
VC spacer (F)
Control switch block
(FK4400)
Loud
speaker
DF tape (Z)
Mechanism
deck
VC heat insulation
sheet
VC-319 board
(Side A)
VC-319 board
(Side B)
MD SECTION
Flexible board
(from the capstan motor)
Flexible board
(from the sensor)
Flexible boards
(from the video head,
from the drum motor)
VC-319
board
Mechanism
deck
Memory stick connector
Control switch block
(FK4400)
Control switch block
(FK4400)
MS shield sheet
(PC105/PC105E)
Noise protection
cushion (FK)
