Sony DCR-PC103E - Page 69

DCR-PC103E/PC104E/PC105/PC105E
COVER
COVER
4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS
4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS
4-81 4-82
FP-467/468/228
FP-467/468/228 FLEXIBLE WIRING BOARD (MD BLOCK)
1
27
1
8
1
8
S902
MODE SWITCH
M902
LOADING
MOTOR
D901
(TAPE LED)
S903
(C. C. DOWN)
S901
(REC PROOF)
MIC902
Q901
TAPE END
SENSOR
FP-468 FLEXIBLE BOARD
FP-467 FLEXIBLE BOARD
1-677-049-
1-686-799-
1-686-798-
11
11
12
DEW
SENSOR
FP-228
FLEXIBLE BOARD
H902
T REEL
SENSOR
H901
S REEL
SENSOR
Q902
TAPE TOP
SENSOR
M
