Sony DCR-PC103E - Page 70

4-83
DCR-PC103E/PC104E/PC105/PC105E
COVER
COVER
CD-444
CD-444 PRINTED WIRING BOARD
CD-444 PRINTED WIRING BOARD
30.3 us
4.0 Vp-p
43.2 us
2.8 Vp-p
7 IC5102 qd,qf
CAMERA REC
6 IC5102 1
CAMERA REC
CD-444 BOARD
30.3 ns
4 IC5101 0
CAMERA REC
30.3 ns
5 IC5101 qa,qs
CAMERA REC
43.2 us
7.9 Vp-p
43.2 us
43.2 us
7.9 Vp-p
2 IC5101 2,3
CAMERA REC
1 IC5101 1,4
CAMERA REC
3 IC5101 8
CAMERA REC
1.0 Vp-p
4.9 Vp-p
5.0 Vp-p
4-4. WAVEFORMS
