Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC103E/PC104E/PC105/PC105E
A-7016-626-A FP-697 BOARD, COMPLETE
**********************
< SWITCH >
S001 1-762-805-21 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
S002 1-786-179-31 SWITCH, PUSH (1KEY)
(PANEL NORMAL/REVERSE)
***********************************************************
A-7016-632-A LI-070 BOARD, COMPLETE
*********************
< BATTERY >
0 BT6401 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
< CONNECTOR >
CN6401 1-816-654-11 FFC/FPC CONNECTOR (LIF) 6P
************************************************************
A-7016-623-A NS-018 BOARD, COMPLETE
**********************
< CAPACITOR >
C6300 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6301 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< DIODE >
D6300 8-719-073-01 DIODE MA111-(K8).S0
D6301 8-719-064-07 DIODE SML-310LTT86
D6302 6-500-512-01 DIODE CL-330IRS-X-TU
< IC >
IC6300 8-742-221-00 HYB IC SBX3055-01
< TRANSISTOR >
Q6300 6-550-235-01 TRANSISTOR DTC114TMT2L
Q6301 8-729-049-92 TRANSISTOR 2SC5585H-T2L
< RESISTOR >
R6300 1-216-805-11 METAL CHIP 47 5% 1/16W
R6302 1-218-951-11 RES-CHIP 680 5% 1/16W
R6303 1-216-609-11 METAL CHIP 18 0.5% 1/10W
R6304 1-216-609-11 METAL CHIP 18 0.5% 1/10W
R6305 1-218-939-11 RES-CHIP 68 5% 1/16W
R6306 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
************************************************************
A-7016-624-A PD-193 BOARD, COMPLETE
**********************
< CAPACITOR >
C600 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C602 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C603 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C604 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C605 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C606 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C609 1-135-213-21 TANTAL. CHIP 3.3uF 20% 25V
C610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C611 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C615 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C616 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C617 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C618 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C619 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C620 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C622 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C624 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C625 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C628 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C629 1-135-213-21 TANTAL. CHIP 3.3uF 20% 25V
< CONNECTOR >
CN600 1-794-997-11 PIN, CONNECTOR 20P
CN602 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN604 1-785-905-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN606 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D604 8-719-050-42 DIODE RD3.3UM-T1B
D605 8-719-073-01 DIODE MA111-(K8).S0
< FERRITE BEAD >
FB600 1-414-760-21 FERRITE 0uH
< IC >
IC600 8-752-109-97 IC CXA3622AR-T4
IC601 8-759-581-11 IC NJM2125F(TE2)
< COIL >
L600 1-469-525-91 INDUCTOR 10uH
L601 1-469-570-11 INDUCTOR 10uH
< TRANSISTOR >
Q603 8-759-054-48 TRANSISTOR UP04601008S0
Q604 8-759-054-48 TRANSISTOR UP04601008S0
Q605 8-729-041-23 TRANSISTOR NDS356AP
Q606 8-729-427-12 TRANSISTOR XP4111-TXE
Q607 8-729-427-42 TRANSISTOR XP4211-TXE
Q609 8-729-050-24 TRANSISTOR MCH6202-TL
Q610 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
Q611 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
< RESISTOR >
R602 1-218-949-11 RES-CHIP 470 5% 1/16W
R605 1-218-990-11 SHORT CHIP 0
R606 1-218-990-11 SHORT CHIP 0
R608 1-218-975-11 RES-CHIP 68K 5% 1/16W
R611 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
FP-697 LI-070 NS-018 PD-193
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
CAUTION :
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
