Sony DCR-PC103E - Page 89

5-25
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC103E/PC104E/PC105/PC105E
R612 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R614 1-208-635-11 RES-CHIP 10 5% 1/16W
R615 1-208-635-11 RES-CHIP 10 5% 1/16W
R616 1-208-635-11 RES-CHIP 10 5% 1/16W
R617 1-208-635-11 RES-CHIP 10 5% 1/16W
R618 1-218-965-11 RES-CHIP 10K 5% 1/16W
R619 1-218-990-11 SHORT CHIP 0
R620 1-218-977-11 RES-CHIP 100K 5% 1/16W
R621 1-218-965-11 RES-CHIP 10K 5% 1/16W
R622 1-216-847-11 METAL CHIP 150K 5% 1/16W
R631 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R633 1-218-990-11 SHORT CHIP 0
R634 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R635 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R636 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R637 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R638 1-218-990-11 SHORT CHIP 0
R641 1-218-977-11 RES-CHIP 100K 5% 1/16W
R642 1-218-989-11 RES-CHIP 1M 5% 1/16W
R643 1-218-990-11 SHORT CHIP 0
************************************************************
A-7016-619-A ST-084 BOARD, COMPLETE (PC105/PC105E)
*************************************************
< CAPACITOR >
C6600 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C6601 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C6602 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C6604 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C6605 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
0 C6606 1-100-454-11 ELECT 60uF 99% 310V
< CONNECTOR >
CN6601 1-815-331-11 CONNECTOR, FPC (ZIF) 19P
< DIODE >
D6600 8-719-073-01 DIODE MA111-(K8).S0
D6601 8-719-073-01 DIODE MA111-(K8).S0
0 D6602 6-500-237-01 DIODE HAU160C030TP
< COIL >
L6600 1-412-027-11 INDUCTOR 2.2uH
< TRANSISTOR >
Q6600 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q6601 8-729-013-31 TRANSISTOR 2SA1588-OY-TE85L
Q6602 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q6603 8-729-048-75 TRANSISTOR CPH3109-TL-E
Q6604 8-729-048-75 TRANSISTOR CPH3109-TL-E
Q6605 6-550-238-01 TRANSISTOR DTA114EMT2L
Q6606 8-729-426-24 TRANSISTOR XP1211-TXE
Q6607 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q6608 8-729-426-24 TRANSISTOR XP1211-TXE
Q6609 8-729-053-74 TRANSISTOR GT8G132(TE12L)
< RESISTOR >
R6600 1-218-947-11 RES-CHIP 330 5% 1/16W
R6601 1-218-965-11 RES-CHIP 10K 5% 1/16W
R6602 1-218-990-11 SHORT CHIP 0
R6604 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R6605 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6606 1-218-941-81 RES-CHIP 100 5% 1/16W
R6607 1-218-937-11 RES-CHIP 47 5% 1/16W
R6608 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6609 1-218-948-11 RES-CHIP 390 5% 1/16W
R6610 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R6612 1-218-953-11 RES-CHIP 1K 5% 1/16W
R6613 1-218-943-11 RES-CHIP 150 5% 1/16W
R6614 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R6615 1-218-937-11 RES-CHIP 47 5% 1/16W
R6616 1-218-989-11 RES-CHIP 1M 5% 1/16W
< TRANSFORMER >
0 T6600 1-437-532-11 TRANSFORMER, DC-DC CONVERTER
< TEST PIN >
TP6600 1-535-757-11 CHIP, CHECKER
************************************************************
A-7016-614-A VF-156 BOARD, COMPLETE
**********************
< CAPACITOR >
C5301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5302 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5401 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5501 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C5502 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C5503 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C5504 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C5505 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5506 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5510 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5511 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5512 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5513 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5514 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5516 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5517 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C5519 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5521 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5523 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5525 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5526 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C5527 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C5528 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C5529 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
PD-193 ST-084 VF-156
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
