DCR-SR21/SR21E/SX21/SX21E_L2
2-4
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
2-1-2. OVERALL SECTION-1
(SR21/SR21E)
Refer to page 2-3 about SX21/SX21E.
Ref. No. Part No. Description
Ref. No. Part No. Description
1. Remove to numerical order (1to 5) in the left figure.
DISASSEMBLY
1 #2 X 1 → #12 X 2 → #2 X 1
Screw
2 53
3 58
52
52
4 57
56
(Note 2)
56
(Note 2)
#2
#2
#2
#12
#12
#2
Overall Section-2
(See page 2-5)
1 51
(Note 1)
5 54
55
59
1
(Claws)
3 (Claw)
2
1
2 (Claws)
2 (Claws)
2 #2 X 2
#2
Left View
#12
BackView
Bottom View
#2
#2
Right View
#2
Left View
Note 2: Direction of Installation of 11 Style Damper (1) as shown in the figure.
5 #2 X 2
Note
Note 1:
ba
c
d
ba
c
d
2
1
1
2
Belt sheet metal
(front 244)
F panel assy
REMOVING METHOD OF F PANEL ASSY
While pushing to the a portion,
twist t he F panel assy in the
direction of the arrow b.
While pulling the belt sheet metal
(front 244) in the direction of the
arrow c, and removing the F panel
assy in the direction of the arrow d.
3 #12 X 1 → #2 X 1
#2
#12
Left View
Bottom View
51 A-1840-005-A PANEL ASSY (B), F (BLACK) (Note 1)
51 A-1840-006-A PANEL ASSY (S), F (SILVER) (Note 1)
52 4-134-206-01 GASKET (OG)
53 A-1840-023-A CABINET (249) ASSY (B), TOP (BLACK)
53 A-1840-024-A CABINET (249) ASSY (S), TOP (SILVER)
54 4-209-700-01 HOLDER, HDD
55 1-882-553-11 FP-1291 FLEXIBLE BOARD
56 4-194-556-01 DAMPER (1), 11STYLE (Note 2)
57 1-840-366-21 HDD (MK8034GAL-80GB) _MASSPRO
(SR21: US, E23, MX, AR/SR21E)
57 1-840-366-51 HDD (MK8034GAL-80GB) _ORIGIN
58 A-1790-730-A CABINET (G (248)) ASSY
59 4-296-788-01 SPACER (249), HDD
#2 2-635-562-31 SCREW (M1.7)
#12 3-080-204-21 SCREW, TAPPING, P2
Ver. 1.1 2011.08
