Parts identification
See pages in parentheses for more details.
MIC (Microphone)
Shutter button (16)
Recording lamp
Flash emitter (33)
MODE selector (PLAY/STILL/
MOVIE) (16)
Lens
Photocell window for flash
Do not block when recording.
PNote
The flash control system may
not work properly when using
your camera with a filter (e.g.
ND filter) or a conversion lens.
(One-push white
balance) button (35)
SPOT METER
button (38)
WHT BAL (white balance)
button (35)
FOCUS AUTO/MANUAL
switch (32)
Focus ring (32)
OPEN (FLASH)
switch (33)
MACRO button (32)
DIGITAL I/O (serial) jack (30)
DIGITAL I/O
(USB) jack
(24)
