5-1
SECTION 5
IC PIN FUNCTION DESCRIPTION
DSRM-E1/E1P
Pin No. Pin Name I/O Function
1 PC0/AN8 I H: Not used
2 PC1/AN9 I H: Not used
3 PC2/AN10 I L: Serial cont H: PAL
4 PC3/AN11 I H: Not used
5 AVSS I Analog ground
6 TEST I L: Fixed
7 X2 O Sub clock, Not used
8 X1 I Sub clock, Not used
9 VSS I Digital ground
10 CLKI I System clock, 8MHz Ceramic vibrator
11 CLKO O System clock, 8MHz Ceramic vibrator
12 RES I Reset from Front micom
13 MD0 I H: Fixed
14 P20 O Not used
15 P21 O Reset (to LANC micom)
16 P22 O Edit interface clock (to Front micom)
17 P23 O Not used
18 P24 O Not used
19 P25 O Not used
20 P26 O Not used
21 P27 O Not used
22 SCK1/P30 O Not used
23 SI1/P31 I Recorder LANC
24 SO1/P32 O Recorder LANC
25 SCK2/P33 I/O LANC, VITC & IR micom communication
26 SI2/P34 I LANC, VITC & IR micom communication
27 SO2/P35 O LANC, VITC & IR micom communication
28 P36 O Not used
29 P37 O Not used
30 VSS I Digital ground
31 V3 NC.
32 V2 NC.
33 V1 NC.
34 VDD I Digital power
35 PA3 O Not used
36 PA2 O Not used
37 PA1 O Not used
38 PA0 O Not used
39 P50 O LANC micom communication (CS)
40 P51 O Not used
41 P52 O Not used
42 P53 O Not used
43 P54 O Not used
44 P55 O Not used
45 P56 O Not used
46 P57 O Not used
47 P60 O Not used
48 P61 O Not used
49 P62 O Not used
50 P63 O Not used
Pin No. Pin Name I/O Function
51 P64 O Not used
52 P65 O Not used
53 P66 O Not used
54 P67 O Not used
55 P70 O Not used
56 P71 O Not used
57 P72 O Not used
58 P73 O Not used
59 P74 O Not used
60 P75 O Not used
61 P76 O Not used
62 P77 O Not used
63 P80 O Not used
64 P81 O Not used
65 P82 O Not used
66 P83 O Not used
67 P84 O Not used
68 P85 O Not used
69 P86 O Not used
70 P87 O Not used
71 P90 I H: Not used
72 P91 I H: Not used
73 P92 I H: Not used
74 P93 I H: Not used
75 P94 I H: Not used
76 P95 I H: Not used
77 P96 I H: Not used
78 P97 I H: Not used
79 VDD I Digital power
80 P10 O Not used
81 P11 O Not used
82 P12 O Not used
83 P13 O Not used
84 P14 O Not used
85 IRQ1/P15 I H: Not used
86 IRQ2/P16 I Communication request (LANC micom)
87 IRQ3/P17 O Not used
88 SCK3/P40 I/O Front micom communication
89 SI3/P41 I Front micom communication
90 SO3/P42 O Front micom communication
91 IRQ0/P43 I Front micom communication (CS)
92 AVDD I Analog power
93 PB0/AN0 I H: Not used
94 PB1/AN1 I H: Not used
95 PB2/AN2 I H: Not used
96 PB3/AN3 I H: Not used
97 PB4/AN4 I H: Not used
98 PB5/AN5 I L: Fixed
99 PB6/AN6 I H: Not used
100 PB7/AN7 I H: Not used
5-1. EDIT Micro Computer HD6433837SA91F (CB-64/64P BOARD IC806)
