7-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board naame.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
AV-40 AV-40P
A-7067-174-A AV-40 BOARD, COMPLETE (DSRM-E1)
*********************************
A-7067-185-A AV-40P BOARD, COMPLETE (DSRM-E1P)
**********************************
< CAPACITOR >
C113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C114 1-104-914-11 TANTAL. CHIP 22uF 20% 16V
C116 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C117 1-104-914-11 TANTAL. CHIP 22uF 20% 16V
C118 1-164-346-11 CERAMIC CHIP 1uF 16V
C119 1-104-914-11 TANTAL. CHIP 22uF 20% 16V
C120 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C121 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C123 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C125 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C126 1-104-823-11 TANTAL. CHIP 47uF 20% 16V
C127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C128 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C129 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C303 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C305 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C307 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C308 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C312 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C313 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C316 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C318 1-162-958-11 CERAMIC CHIP 270PF 5% 50V
C319 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C320 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C321 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C322 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C323 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C324 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C325 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C326 1-135-091-00 TANTALUM CHIP 1uF 20% 16V
C329 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C334 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C335 1-115-156-11 CERAMIC CHIP 1uF 10V
C337 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C338 1-164-473-11 CERAMIC CHIP 820PF 5% 50V
C339 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C341 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C342 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C343 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C344 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C347 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C348 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C350 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C351 1-111-253-11 TANTAL. CHIP 100uF 20% 6.3V
C352 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C355 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C356 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C358 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C365 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C366 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DSRM-E1)
C366 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(DSRM-E1P)
C367 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DSRM-E1)
C367 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(DSRM-E1P)
C368 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C369 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DSRM-E1)
C370 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(DSRM-E1)
C370 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(DSRM-E1P)
C371 1-164-346-11 CERAMIC CHIP 1uF 16V
C372 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C373 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C501 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C502 1-164-315-11 CERAMIC CHIP 470PF 2% 50V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C507 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C508 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C509 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C510 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C511 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C512 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C513 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C514 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C515 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(DSRM-E1P)
