7-5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< JACK >
J101 1-691-110-21 JACK, PIN 3P (MONITOR OUT)
< COIL >
L101 1-424-522-21 INDUCTOR 0uH
L102 1-424-674-11 INDUCTOR 0uH
L103 1-424-524-21 INDUCTOR 0uH
L302 1-414-754-11 INDUCTOR 10uH
L303 1-412-951-11 INDUCTOR 10uH
L304 1-412-953-11 INDUCTOR 15uH (DSRM-E1)
L304 1-412-951-11 INDUCTOR 10uH (DSRM-E1P)
L305 1-412-951-11 INDUCTOR 10uH
L306 1-412-951-11 INDUCTOR 10uH
L307 1-412-951-11 INDUCTOR 10uH
L308 1-412-951-11 INDUCTOR 10uH (DSRM-E1)
L308 1-412-958-21 INDUCTOR 39uH (DSRM-E1P)
L309 1-412-951-11 INDUCTOR 10uH (DSRM-E1)
L309 1-412-958-21 INDUCTOR 39uH (DSRM-E1P)
L310 1-412-951-11 INDUCTOR 10uH
L501 1-414-754-11 INDUCTOR 10uH
L503 1-414-754-11 INDUCTOR 10uH
L504 1-414-754-11 INDUCTOR 10uH
L505 1-412-951-11 INDUCTOR 10uH
L701 1-412-951-11 INDUCTOR 10uH
L702 1-412-951-11 INDUCTOR 10uH
L703 1-412-951-11 INDUCTOR 10uH
L704 1-414-135-11 FERRITE 0uH
L705 1-412-951-11 INDUCTOR 10uH
L706 1-410-381-11 INDUCTOR CHIP 10uH
< LINE FILTER >
LF101 1-411-312-11 FILTER, COMMON MODE
< TRANSISTOR >
Q103 8-729-037-92 TRANSISTOR 2SD2216J-R(TX).SO
Q105 8-729-823-84 TRANSISTOR FP102-TL
Q304 8-729-402-81 TRANSISTOR XN4501-TW
Q305 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q306 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q307 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q309 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q310 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q311 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q315 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q317 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q318 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q320 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q501 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q502 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q503 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q504 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q505 8-729-427-72 TRANSISTOR XP4501-TXE
Q506 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q507 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q508 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q509 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q510 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q511 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q512 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q513 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q514 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q701 8-729-905-35 TRANSISTOR 2SC4081T106R
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/16W
R103 1-216-809-11 METAL CHIP 100 5% 1/16W
R104 1-216-809-11 METAL CHIP 100 5% 1/16W
R105 1-216-809-11 METAL CHIP 100 5% 1/16W
R106 1-216-809-11 METAL CHIP 100 5% 1/16W
R107 1-216-809-11 METAL CHIP 100 5% 1/16W
R108 1-216-809-11 METAL CHIP 100 5% 1/16W
R113 1-216-809-11 METAL CHIP 100 5% 1/16W
R114 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-836-11 METAL CHIP 18K 5% 1/16W
R120 1-216-821-11 METAL CHIP 1K 5% 1/16W
R121 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R122 1-216-839-11 METAL CHIP 33K 5% 1/16W
R123 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R124 1-216-810-11 METAL CHIP 120 5% 1/16W
R125 1-218-865-11 RES,CHIP 5.6K 0.50% 1/16W
R126 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R127 1-218-853-11 RES,CHIP 1.8K 0.50% 1/16W
R128 1-216-821-11 METAL CHIP 1K 5% 1/16W
R129 1-216-864-11 METAL CHIP 0 5% 1/16W
R132 1-216-844-11 METAL CHIP 82K 5% 1/16W
R136 1-216-295-91 SHORT 0
R137 1-216-295-91 SHORT 0
R138 1-216-295-91 SHORT 0
R139 1-216-295-91 SHORT 0
R140 1-216-295-91 SHORT 0
R311 1-216-833-11 METAL CHIP 10K 5% 1/16W
R312 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R313 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R314 1-216-821-11 METAL CHIP 1K 5% 1/16W
R315 1-216-813-11 METAL CHIP 220 5% 1/16W
R316 1-216-821-11 METAL CHIP 1K 5% 1/16W
R317 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R318 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R319 1-216-821-11 METAL CHIP 1K 5% 1/16W
R320 1-216-817-11 METAL CHIP 470 5% 1/16W
R321 1-216-813-11 METAL CHIP 220 5% 1/16W
R322 1-216-821-11 METAL CHIP 1K 5% 1/16W
R323 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R324 1-216-864-11 METAL CHIP 0 5% 1/16W
R325 1-216-821-11 METAL CHIP 1K 5% 1/16W
R326 1-216-813-11 METAL CHIP 220 5% 1/16W
R327 1-216-821-11 METAL CHIP 1K 5% 1/16W
R328 1-216-864-11 METAL CHIP 0 5% 1/16W
R329 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R330 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R333 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R335 1-216-817-11 METAL CHIP 470 5% 1/16W
R337 1-216-864-11 METAL CHIP 0 5% 1/16W
R338 1-216-864-11 METAL CHIP 0 5% 1/16W
R339 1-216-821-11 METAL CHIP 1K 5% 1/16W
R340 1-216-864-11 METAL CHIP 0 5% 1/16W
R343 1-216-821-11 METAL CHIP 1K 5% 1/16W
R344 1-216-813-11 METAL CHIP 220 5% 1/16W
R345 1-216-833-11 METAL CHIP 10K 5% 1/16W
AV-40 AV-40P
