7-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R574 1-216-817-11 METAL CHIP 470 5% 1/16W
R575 1-216-817-11 METAL CHIP 470 5% 1/16W
R576 1-216-817-11 METAL CHIP 470 5% 1/16W
R577 1-216-817-11 METAL CHIP 470 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R702 1-216-833-11 METAL CHIP 10K 5% 1/16W
R703 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R704 1-216-864-11 METAL CHIP 0 5% 1/16W
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R707 1-218-862-11 RES,CHIP 4.3K 0.50% 1/16W
(DSRM-E1)
R707 1-218-859-11 RES,CHIP 3.3K 0.50% 1/16W
(DSRM-E1P)
R708 1-218-269-11 RES,CHIP 360 5% 1/16W
R709 1-216-849-11 METAL CHIP 220K 5% 1/16W
R710 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARIABLE RESISTOR >
RV101 1-241-474-11 RES, ADJ, CERMET 470
RV501 1-241-475-11 RES, ADJ, CERMET 1K
< SWITCH >
S101 1-572-244-11 SWITCH, SLIDE (POWER)
< VIBRATOR >
X301 1-579-466-11 VIBRATOR, CRYSTAL (3.58MHz) (DSRM-E1)
X301 1-579-661-21 OSCILLATOR, CRYSTAL (4.43MHz)
(DSRM-E1P)
X302 1-577-165-11 VIBLATOR, CERAMIC (500kHz)
X501 1-579-466-11 VIBRATOR, CRYSTAL (3.58MHz) (DSRM-E1)
X501 1-579-661-21 OSCILLATOR, CRYSTAL (4.43MHz)
(DSRM-E1P)
A-7067-173-A CB-64 BOARD, COMPLETE (DSRM-E1)
*******************************
A-7067-184-A CB-64P BOARD, COMPLETE (DSRM-E1P)
*********************************
< CAPACITOR >
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C807 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C808 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C810 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C811 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C812 1-104-910-11 TANTAL. CHIP 15uF 20% 10V
C813 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C814 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C815 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C816 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C817 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C818 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C819 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C820 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C821 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C822 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C823 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C824 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C825 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C826 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C832 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C833 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
< CONNECTOR >
CN801 1-774-287-11 CONNECTOR, FFC/FPC 22P
CN802 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D801 8-719-422-97 DIODE MA8091-M-TX
D802 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D803 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D805 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D806 8-719-800-76 DIODE 1SS226-TE85L
D807 8-719-800-76 DIODE 1SS226-TE85L
D808 8-719-800-76 DIODE 1SS226-TE85L
D809 8-719-800-76 DIODE 1SS226-TE85L
D810 8-719-820-05 DIODE 1SS181-TE85L
D811 8-719-422-64 DIODE MA8062-M-TX
D812 8-719-820-05 DIODE 1SS181-TE85L
D813 8-719-422-97 DIODE MA8091-M-TX
D814 8-719-422-64 DIODE MA8062-M-TX
D815 8-719-422-64 DIODE MA8062-M-TX
D816 8-719-422-64 DIODE MA8062-M-TX
D817 8-719-820-05 DIODE 1SS181-TE85L
D818 8-719-801-78 DIODE 1SS184-TE85L
D823 8-719-422-97 DIODE MA8091-M-TX
D824 8-719-422-97 DIODE MA8091-M-TX
< FUSE >
! F801 1-533-380-21 FUSE, CHIP
< FERRITE BEAD >
FB801 1-414-552-11 FERRITE 0UH
FB802 1-414-552-11 FERRITE 0UH
FB803 1-414-552-11 FERRITE 0UH
FB804 1-414-552-11 FERRITE 0UH
FB805 1-414-552-11 FERRITE 0UH
FB806 1-414-552-11 FERRITE 0UH
FB807 1-414-552-11 FERRITE 0UH
FB808 1-414-552-11 FERRITE 0UH
FB809 1-414-552-11 FERRITE 0UH
FB810 1-414-552-11 FERRITE 0UH
FB811 1-414-552-11 FERRITE 0UH
FB812 1-414-552-11 FERRITE 0UH
FB813 1-414-552-11 FERRITE 0UH
FB814 1-414-552-11 FERRITE 0UH
< IC >
IC803 8-759-544-54 IC RH5VL24AA-T1
IC804 8-759-503-60 IC S-80740AN-D4-T1
IC805 8-759-427-49 IC HD6433837SA90F
IC806 8-759-427-50 IC HD6433837SA91F
IC807 8-759-270-03 IC SN74HC174ANS-E20
AV-40 AV-40P CB-64 CB-64P
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
