7-9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C110 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C111 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C112 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
< CONNECTOR >
CN101 1-506-487-11 PIN, CONNECTOR 8P
CN102 1-770-690-11 CONNECTOR, FFC/FPC 7P
< DIODE >
D101 8-719-800-76 DIODE 1SS123-T1
D102 8-719-800-76 DIODE 1SS123-T1
D103 8-719-106-80 DIODE RD13M-T1B2
D104 8-719-421-59 DIODE MA3075WA-(TX)
D105 8-719-800-76 DIODE 1SS123-T1
D106 8-719-800-76 DIODE 1SS123-T1
D107 8-719-157-33 DIODE RD6.2M-T1B
D108 8-719-047-18 DIODE SML-010DT-T87 (MENU)
D109 8-719-047-18 DIODE SML-010DT-T87 (PREVIEW)
D110 8-719-047-18 DIODE SML-010DT-T87 (EDIT)
D111 8-719-984-33 DIODE SML-010MT-T87 (PLAYER)
D112 8-719-047-18 DIODE SML-010DT-T87 (RECORDER)
< FERRITE BEAD >
FB101 1-414-552-11 FERRITE 0UH
FB102 1-414-552-11 FERRITE 0UH
FB103 1-414-552-11 FERRITE 0UH
FB104 1-414-552-11 FERRITE 0UH
FB105 1-414-552-11 FERRITE 0UH
FB106 1-414-552-11 FERRITE 0UH
< IC >
IC101 8-759-503-60 IC S-80740AN-D4-T1
IC102 8-759-350-90 IC MB89131PFM-G-274-BND
IC103 8-759-157-17 IC PQ05SZ1U
IC104 8-759-032-01 IC MC74HC00AF-T2
IC106 8-759-636-56 IC M66311FP-TP
< JUMPER >
JS103 1-216-295-91 SHORT 0
JS104 1-216-295-91 SHORT 0
< COIL >
L101 1-412-951-11 INDUCTOR 10uH
< TRANSISTOR >
Q101 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q102 8-729-140-47 TRANSISTOR 2SC3735-T1B-B34
Q103 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q104 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q105 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q106 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q107 1-801-806-11 TRANSISTOR DTC144EKA-T146
< RESISTOR >
R101 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R103 1-216-025-91 RES,CHIP 100 5% 1/10W
R104 1-216-025-91 RES,CHIP 100 5% 1/10W
R105 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R106 1-216-049-91 RES,CHIP 1K 5% 1/10W
R107 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R108 1-216-041-00 METAL CHIP 470 5% 1/10W
R109 1-216-073-00 METAL CHIP 10K 5% 1/10W
R110 1-216-025-91 RES,CHIP 100 5% 1/10W
R111 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R112 1-216-025-91 RES,CHIP 100 5% 1/10W
R113 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R114 1-216-049-91 RES,CHIP 1K 5% 1/10W
R115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R116 1-216-073-00 METAL CHIP 10K 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-073-00 METAL CHIP 10K 5% 1/10W
R119 1-216-073-00 METAL CHIP 10K 5% 1/10W
R120 1-216-049-91 RES,CHIP 1K 5% 1/10W
R121 1-216-073-00 METAL CHIP 10K 5% 1/10W
R122 1-216-025-91 RES,CHIP 100 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-025-91 RES,CHIP 100 5% 1/10W
R125 1-216-073-00 METAL CHIP 10K 5% 1/10W
R126 1-216-073-00 METAL CHIP 10K 5% 1/10W
R127 1-216-089-91 RES,CHIP 47K 5% 1/10W
R128 1-216-033-00 METAL CHIP 220 5% 1/10W
R129 1-216-073-00 METAL CHIP 10K 5% 1/10W
R130 1-216-033-00 METAL CHIP 220 5% 1/10W
R131 1-216-089-91 RES,CHIP 47K 5% 1/10W
R132 1-216-073-00 METAL CHIP 10K 5% 1/10W
R133 1-216-033-00 METAL CHIP 220 5% 1/10W
R134 1-216-031-00 METAL CHIP 180 5% 1/10W
R135 1-216-089-91 RES,CHIP 47K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-033-00 METAL CHIP 220 5% 1/10W
R138 1-216-089-91 RES,CHIP 47K 5% 1/10W
R139 1-216-073-00 METAL CHIP 10K 5% 1/10W
R140 1-216-089-91 RES,CHIP 47K 5% 1/10W
R141 1-216-841-11 METAL CHIP 47K 5% 1/16W
< SWITCH >
S101 1-692-682-11 SWITCH, TACTILE (RUBBER) (REC)
S102 1-692-682-11 SWITCH, TACTILE (RUBBER) (PREVIEW)
S103 1-692-682-11 SWITCH, TACTILE (RUBBER) (STOP)
S104 1-692-682-11 SWITCH, TACTILE (RUBBER) (EDIT)
S105 1-692-682-11 SWITCH, TACTILE (RUBBER) (PLAY)
S106 1-692-682-11 SWITCH, TACTILE (RUBBER) (MENU)
S107 1-692-682-11 SWITCH, TACTILE (RUBBER) (MARK IN)
S108 1-692-682-11 SWITCH, TACTILE (RUBBER) (PAUSE)
S109 1-692-682-11 SWITCH, TACTILE (RUBBER) (CANCEL)
S110 1-692-682-11 SWITCH, TACTILE (RUBBER) (MARK OUT)
S111 1-692-682-11 SWITCH, TACTILE (RUBBER) (PLAYER)
S112 1-692-682-11 SWITCH, TACTILE (RUBBER) (RECORDER)
S113 1-771-128-11 SWITCH, TACTILE (SEL/PUSH EXECUTE)
< VIBRATOR >
X101 1-760-458-21 VIBRATOR, CRYSTAL (32.768kHz)
X102 1-767-192-11 VIBRATOR, CERAMIC (4.195MHz)
CM-58
