9
Part names
H Right stick/R3 button*
I Fn button
Use in combination with other buttons.
• Fn button + action buttons: switch between profiles
• Fn button + (options) button: customise a profile
• Fn button + up/down button: adjust volume of
headphones
• Fn button + left/right button: adjust audio balance
J Speaker
K (PS) button
L Headset jack
M Microphone
N (mute) button
O Left stick/L3 button*
* The stick caps are changeable ( page 12).
A B C D E C F G
H
O I N M L K J I
Front
A Directional buttons
B (create) button
C Light bar
D Touch pad/touch pad button
E Player indicator
F (options) button
G Action buttons
button button button button
EN
